(888) 312-8812 Login SignupMONROE 65419 Magnum Suspension Shock Absorber
Tap to view 5 more
MSRP: $147.39
$7799
Save $69.40
Limited availability at this price!
In Stock
Get it by Wednesday, Jul 8
MONROE 65419 Part Description
Manufacturer
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65419 Specifications
Product Attributes
| Compressed Length | 11.625 IN |
| Compressed Length | 295.3 MM |
| Extended Length | 17 in |
| Extended Length | 431.8 MM |
| Travel Length | 5.375 in |
| Travel Length | 136.5 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Upper Mount Code | LS54 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173195 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65419 Cross References
| Brand | Part Number |
|---|---|
| 85911, 89436, 65419MM, MAE65419 | |
| Alliance Parts | ABPN32O900015, ABPN32G900015 |
| BULLDOG HD SHOCKS | HD1215-0040 |
| Bulldog HD | HD12150040 |
| CHEVROLET | 3919570 |
| CUSH | C0062D, C0078 |
| Cush Suspensions | C0062D, C0078 |
| Dayton Parts | 441850005419 |
| EUCLID | M85000 |
| FCS | F347332, F347352 |
| FOX COMMERCIAL TRUCK SHOCKS | 98031014 |
| FREIGHTLINER | 90044162 |
| FleetPride | 650419PB |
| GABRIEL | 85911, 85000, 89436, 654951, 83128, 671948, 65911, 654907, 665761, 665746, 83389 |
| GM | 3919570 |
| General Motors | 3919570 |
| Gold Shock Absorber | 8150242, 8180262, 9180136 |
| HALDEX | SA65419 |
| HENDRICKSON | S23566, B26652, S23361, B24088, A20001, B23566, 520001, B23361, S26652 |
| Hendrickson | S20001, S22345, S22715, S24088 |
| Holland | 90044162, 90045298, 90045337 |
| INTERNATIONAL | AMS650419 |
| KONI | 881644 |
| KYB | 341626 |
| KYB AMERICA LLC. | 341626 |
| MACK | 650419MT, 650419 |
| MERITOR | M85000, M89436, M83128, 665724 |
| MONROE VINTAGE | 70623, 16616, 650419 |
| Monroe Shocks & Struts | 16616, 650419, 70623 |
| NAPA Shocks | 65419 |
| NEWAY | 90045337, 90044162, 90045564, 57365419, 57306608 |
| Neway | 90045298 |
| OEM | 90045337, S22345, S23361, S22715, 90045298, S24088, S20001, 90044162 |
| POWER10 PARTS | HT-S20001 |
| REYCO GRANNING | 70009801 |
| SACHS NORTH AMERICA | 315552, 315411 |
| SAF-HOLLAND | 90044162 |
| STOUGHTON TRAILERS | HTA200001, NW90044162 |
| Sachs | 315552, 315411 |
| TORQUE PARTS | TR85000 |
| TWIN COACH | 90044162 |
| UTILITY TRAILER MANUFACTURING | A20001 |
| VOLVO / WHITE / GMC | RCSA5000, RCSA3128, 3919570, SA3128, SA5000 |
| Volvo GM Heavy Truck | 3919570, RCSA3128, RCSA5000, SA3128, SA5000 |
| Volvo White | SA5000 |
| WATSON & CHALIN | 10147HD |
