(888) 312-8812 Login SignupMERITOR M85000 Suspension Shock Absorber, Standard, 2.38 in. Body Diameter, 1.57 in. Shock Absorber Bore Size
Tap to view 1 more
SHIPS TODAY
MSRP: $116.01
$7749
Save $38.52
Limited availability at this price!
In Stock
Get it by Friday, Jul 17
MERITOR M85000 Part Description
Manufacturer
Product Description
Shock Absorber
Features & Benefits
- Damps suspension travel using a 5.16-inch stroke to maintain tire-to-road contact
- Features a 16.93-inch extended and 11.77-inch collapsed measurement for specific fitment verification
- Utilizes a 1.375-inch large-bore piston to handle the thermal loads of heavy-duty operation
- Reduces wheel hop and axle walk during hard braking or acceleration on uneven surfaces
- Supports consistent ride height stability by controlling air spring rebound rates
- Includes heavy-duty bonded rubber bushings to minimize mounting point wear and noise
Meritor Suspension Shock Absorber
The Meritor Suspension Shock Absorber is a heavy-duty gas-charged damper engineered for primary suspension positions on Class 8 trucks. This Meritor M85000 shock features a 11.77-inch collapsed length and a 16.93-inch extended length, providing a total stroke of 5.16 inches for managing axle travel. It is built with a 1.375-inch bore and utilizes reinforced end-mount bushings to withstand the high-lateral forces of loaded vocational and over-the-road hauling. The internal valving is tuned to control both compression and rebound cycles, preventing the rapid axle oscillation that causes tire cupping and high-frequency vibration through the chassis.
MERITOR M85000 Specifications
Product Attributes
| Body Diameter (in.) | 2.38 in. |
| Body Diameter (mm) | 60.5 mm |
| Bore (in.) | 1.57 in. |
| Bore (MM) | 40 mm |
| Brand | Meritor |
| Collapsed Length (in.) | 11.77 in. |
| Collapsed Length (mm) | 299 mm |
| Dust Shield Diameter (in.) | 2.76 in. |
| Dust Shield Diameter (mm) | 70 mm |
| Extended Length (in.) | 16.93 in. |
| Extended Length (mm) | 430 mm |
| Family Code | 41FCST |
| Hydraulic Stop | Yes |
| Pallet Quantity | 198 |
| Stroke | 131 mm |
| Stroke Inch | 5.16 in. |
| Type | Standard |
| Weight | 7.00 |
| Body Diameter | 2.38 in. |
| Compressed Length | 11.77 in. |
| Dust Shield Diameter | 2.76 in. |
| Extended Length | 16.93 in. |
| Shock Stroke | 131 mm |
| Shock Absorber Bore Size | 1.57 in. |
| Type | Standard |
MERITOR M85000 Cross References
| Brand | Part Number |
|---|---|
| 85000, 66893M, GAB85000, TDAM85000, RCSA5000, REA85000, S1667HAA, SA5000, SAF90044162, TEN65419, TEN66608, WA0185000 | |
| ARVIN MERITOR | 654907 |
| AUTOMANN | A85000 |
| BENSON TRUCK BODIES | A20002 |
| BENSON TRUCK BODIES INC. | A-20002 |
| DAYTON PARTS BATCO | 341S20002, 341S23566, M65419 |
| DELCO | 508-9, 5089 |
| EAST MANUFACTURING CORP. | 517-05110-20, 517-05805-20 |
| EAST TRAILER | A20002 |
| FLEETRITE | AMS600104, AMS650419, AMS660104 |
| FREIGHTLINER | 16-14759-000 |
| Fleetrite | AMS600103, AMS600167, AMS650416, AMS660195 |
| Freightliner | 1614759000 |
| GABRIEL | 85000, 57639, 728600, 89436 |
| GREAT DANE TRAILER | HENS-20001, HENS-20002, HENS-23566, HENS-24088 |
| HALDEX | SA56419, SA65416, SA65419, SA66634, SA66893 |
| HENDRICKSON | S-20001, S-20002, S-23566, S-24088, S-1667, S-26652, A14583, A1667, B23566, B24088, S1667, S20002, S20001 |
| HENDRICKSON TRAILER SUSPENSION SYSTEMS | A-20002, B-23566, B-23013, A-20001, A-1667, B-24088, S-1667, A-14583, A-1668, B-26652, S-14583, S-1668, S-20001, S-20002, S-23013, S-23566, S-24088, S-26652, 665531, 665536, 665766, 665756, 654951, 671948 |
| KONI | 88-1644 |
| KYB | 341625, 341626 |
| MERITOR | M89436 |
| MONROE | 65419 |
| MOTORCRAFT | CAX-893 |
| Monroe Shocks & Struts | 65419 |
| Motorcraft | CAX893 |
| NEWAY | AR718CHD, 90044008, 90044071, 90044081, 90044086, 90044981, 90044982, 90044992, 90045299 |
| ORION BUS INDUSTRIES | 020273541-4, 202735414 |
| PAGE SUSP. | 1080099 |
| REYCO | 1880001 |
| REYCO SUSPENSION | 18800-01 |
| RIDEWELL | 1250563B000, 1270563B000 |
| RIDEWELL CORPORATION | 1270563B000, 1250563B000 |
| Reyco Granning | 1880001 |
| Ridewell Corp | 1250563B000, 1270563B000 |
| SAF-HOLLAND | 90045299, 90044992, 90044008, 57639, 90044071, 90044081, 90044086, 90044981, 90044982, 90044991, AR-718-C-HD |
| STOUGHTON TRAILERS | HTA20001, HTA20002 |
| STOUGHTON TRAILERS INC. | HTA20001, HTA20002 |
| THOMAS SCHOOL | 61310232 |
| THOMAS SCHOOL BUS | 61310232 |
| TRAILMOBILE CANADA CORP. | 43-6-118, 43-8-013, 90044992, 43-4-237, 43-4-277, 43-6-028 |
| TWIN COACH | AR-718-C-HD, AR718CHD |
| Trailmobile | 434277, 434237, 436028, 436118, 438013, 90044992 |
| VOLVO | 1091367 |
| WABASH NATIONAL | FLL85000-07I, HENS-20001, HENS-20002, HENS-23566, HENS-24088, NEW900-45-299 |
| WATSON & CHALIN MFG. INC. | 10147HD, 665724, 665862 |
| WORLD AMERICAN | WA01-85000 |
