(888) 312-8812 Login SignupMONROE 66201 Suspension Shock Absorber - Premium Gas, 13.42 Inch, LS77/LS34 Mount
Tap to view 3 more
$5549
Limited availability at this price!
In Stock
Get it by Friday, Dec 19
MONROE 66201 Part Description
Manufacturer
Features & Benefits
- Designed to provide firm control, offering a comfortable ride for hardworking vehicles
- High-capacity bore and oversized 2-inch reserve tube for optimal shock absorption
- Self-lubricating fluid seal minimizes friction and reduces wear on piston rod
- Nitrogen gas charge helps in maintaining consistent tire contact for better handling
Monroe Gas-Magnum 60 Series Suspension Shock Absorber
The Monroe Gas-Magnum 60 Series Suspension Shock Absorber promises firm control and longevity for your vehicle. Tailored for midsize and full-size trucks and vans, this shock absorber ensures a controlled, smooth ride every time. Its heavy-duty nitrocarburized rod and sintered iron piston boost durability, extending the shock absorber’s life. The increased bore size and a sizable 2-inch reserve tube enhance oil capacity, optimizing shock absorption and efficiency. With a nitrogen gas charge, this Monroe 66201 ensures consistent tire-to-road contact, which improves handling and reduces aeration, preventing shock fade. A self-lubricating fluid seal also reduces friction against the piston rod, minimizing wear. Regardless of extreme weather, Monroe's OE all-weather fluid ensures a consistently dependable performance.
MONROE 66201 Specifications
Product Attributes
| Lower Mount Code | LS34 |
| Upper Mount Code | LS77 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 9.6 IN |
| Extended Length | 13.42 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 2.7/8" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 3.82 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 2.7/16" Sleeve OAL |
| Compressed Length | 243.8 MM |
| Extended Length | 340.9 MM |
| Travel Length | 97 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Adjustable Rebound | No |
| Compressed Length (in) | 9.6 |
| Adjustable Compression | No |
| Adjustable Ride Height | No |
| Grade Type | Premium |
| Extended Length (in) | 13.42 |
| Lower Mount Code | LS34 |
| Extended Length (mm) | 340.9 |
| Active or Passive Suspension | Passive |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 2.7/16" Sleeve OAL |
| Upper Mount Code | LS77 |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Travel Length (in) | 3.82 |
| Compressed Length (mm) | 243.8 |
| Travel Length (mm) | 97 |
| Mounting Hardware Included | No |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598126481 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 66201 Part Interchanges
| Brand | Part Number |
|---|---|
| Kenworth | 12018002, 25523024, R716009, 25523013 |
| Peterbilt | 12018006, 25523024, R716009 |
| OEM | R716009, 25523024, 12018006, 12018002 |
| Gabriel | 83081 |
| KENWORTH | 12018002 |
| NAPA Shocks | 66201 |
| FCS | F347299, F347222, F347204, F347275, F347255 |
| Link | 12018002, 12018006, R716009 |
MONROE 66201 Fits Vehicles
- Kenworth W990 (2019-2023)
- Peterbilt 567 (2016-2023)
- Kenworth T880 (2020-2023)
- Peterbilt 348 (2010-2020)
- Peterbilt 587 (2011-2015)
- Peterbilt 579 (2013-2022)
- Kenworth T680 (2013-2024)
- Peterbilt 386 (2006-2016)
- Kenworth T660 (2008-2019)
- Peterbilt 384 (2010-2016)
MONROE 66201 Cross References
We have 8 alternatives for the 66201 by MONROE:
