MONROE 65494 Part Description
Manufacturer
Product Description
Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65494 Specifications
Product Attributes
| Compressed Length | 15.5 IN |
| Compressed Length | 393.7 MM |
| Extended Length | 24.8125 in |
| Extended Length | 630.2 MM |
| Travel Length | 9.313 in |
| Travel Length | 236.6 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 2.9/16" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS62 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 4" Sleeve OAL |
| Upper Mount Code | LS61 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173942 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65494 Cross References
| Brand | Part Number |
|---|---|
| 65494MM, MAE65494 | |
| Alliance Parts | ABPN32O900080, ABPN32G900080 |
| Automann | A85061 |
| BULLDOG HD SHOCKS | HD1215-0074 |
| Dayton Parts | M65494, 44185061 |
| FCS | F347205, F347207, F347234 |
| FOX COMMERCIAL TRUCK SHOCKS | 98031018, 98031013 |
| Flagg Suspension Parts | F65494 |
| Fleetrite | SA55044, AMS65494 |
| GABRIEL | 85061, 85098, 89502, 89450 |
| HALDEX | SA65494 |
| MACK | 14QK431M, 20973993, 14QK3107M, 14QK3114M, 25633133, 21436096 |
| MERITOR | M85061, M89450, M85066 |
| MONROE VINTAGE | 650130 |
| Mack | 23292027, 23292028 |
| Monroe Shocks & Struts | 650130 |
| NAPA Shocks | 65494 |
| OEM | 21436096, 21436086, 20433424, 20513881, 14QK3107M, 20973993 |
| POWER10 PARTS | SSA-85098 |
| SACHS NORTH AMERICA | 315607, 141700005838, 410036, 315606, 141700005839 |
| Sachs | 315607, 141700005838, 410036, 315606, 141700005839 |
| TORQUE PARTS | TR85061 |
| VOLVO / WHITE / GMC | RCSA5066, 21436086, 20433428, SA5061, 21436096, 20513881, 20433423, RCSA5061, SA5066, 20433424, 8078195 |
| Volvo | 20433424, 20513881, 21436086 |
| Volvo GM Heavy Truck | 20433423, 20433424, 20433428, 20513881, 21436086, 21436096, 8078195, RCSA5061, RCSA5066, SA5061, SA5066 |
| Volvo Truck | 23288402, 23288403 |
| WORLD AMERICAN | WA01-85061 |
| World American | WA0185061 |
MONROE 65494 Fits Vehicles
- Mack Anthem (2018-2024)
- Volvo VNR (2018-2024)
- Volvo VNX (2014-2017)
- Mack CX (1998-2005)
- Volvo VNL (2000-2024)
- Volvo VNM (2000-2018)
- Volvo VAH (2011-2018)
- Volvo VN (1998-1999, 2004)
- Mack CHN (2004-2007)
- Mack CXU (2008-2019)
- Mack CXP (2006-2007)
