(888) 312-8812 Login SignupMONROE 65495 Suspension Shock Absorber - Premium Gas, 30.5 Inch Extended, LS87/LS80
Tap to view 5 more
MSRP: $197.73
$10399
Save $93.74
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 31
MONROE 65495 Part Description
Manufacturer
Features & Benefits
- Rod strength reduces flexing during long compression events on rural roads
- Seal system helps maintain internal fluid balance across changing climates
- Body construction resists wear generated during frequent full-stroke movements
- Surface coating protects against rust created by roadside moisture pockets
- Extended reach aids stability for vehicles using taller or modified springs
Monroe Shock
The Monroe Shock performs reliably on commercial vehicles that experience extended travel over rural connector roads where rolling hills and longer suspension strokes are common. Its increased extended length benefits taller suspension setups that articulate further when vehicles descend or crest gradual elevation changes. The gas-charged design reduces bounce during return strokes, maintaining calmer body behavior after uneven road contact. This configuration helps manage weight shift in vehicles that carry moderately heavy cargo across varied terrain. The Monroe 65495 helps maintain strategic damping control for vehicles encountering longer suspension cycles in open-country driving.
MONROE 65495 Specifications
Product Attributes
| Lower Mount Code | LS80 |
| Upper Mount Code | LS87 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Part Description | Shock Absorber |
| Compressed Length | 18.3594 IN |
| Dust Shield Material | Metal |
| Extended Length | 30.5 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.3/4" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 12.141 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 3.9/16" Sleeve OAL |
| Compressed Length | 466.3 MM |
| Extended Length | 774.7 MM |
| Travel Length | 308.4 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Adjustable Rebound | No |
| Adjustable Compression | No |
| Adjustable Ride Height | No |
| Compressed Length (mm) | 466.3 |
| Extended Length (mm) | 774.7 |
| Lower Mount Code | LS80 |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.3/4" Sleeve OAL |
| Grade Type | Premium |
| Travel Length (in) | 12.141 |
| Travel Length (mm) | 308.4 |
| Compressed Length (in) | 18.3594 |
| Mounting Hardware Included | No |
| Active or Passive Suspension | Passive |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 3.9/16" Sleeve OAL |
| Upper Mount Code | LS87 |
| Extended Length (in) | 30.5 |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173959 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65495 Part Interchanges
| Brand | Part Number |
|---|---|
| Kenworth | C711002, c711016, C711016A, C716015 |
| Peterbilt | C711002, c711016, C716000, C716015, C711016 |
| FOX Commercial Truck Shocks | 98031008 |
| OEM | C716015, C711016A, c711016, C716000, C711002 |
| PETERBILT | C711016PLUS |
| Sachs | 315424 |
| Meritor | M85067 |
| VOLVO / WHITE / GMC | RCSA5067, SA5067 |
| Gabriel | 85067, 671794, 89451 |
| KYB | 341614, 441600, 341621, 341620 |
| KENWORTH | C711016A |
| Haldex | SA65495 |
| Paccar Parts | C711002, C711016, C711016A, C711016PLUS, C716000, C716015 |
| Volvo GM Heavy Truck | RCSA5067, SA5067 |
| NAPA Shocks | 65495 |
| Automann | A85067 |
| Road Choice | SA5000, SA5067 |
| Bulldog HD | HD12150034 |
| FCS | F347215, F347306, F343376, F346599, F343378, F343368, F344355, F344353, F346598, F346633, F344342, F344343, F347303, F343375 |
| Alliance Truck Parts | ABPN32O900020, ABPN32G900020 |
| Dayton Parts | 44185067 |
MONROE 65495 Fits Vehicles
- Peterbilt 382 (2011-2017)
- Kenworth T800 (2001-2021)
- Peterbilt 587 (2011-2015)
- Kenworth T700 (2011-2016)
- Peterbilt 389 (2008-2018)
- Peterbilt 579 (2013-2020)
- Kenworth T880 (2014-2020)
- Kenworth T680 (2013-2024)
- Peterbilt 388 (2008-2015)
- Peterbilt 386 (2006-2016)
- Peterbilt 367 (2008-2020)
- Kenworth T660 (2008-2019)
- Peterbilt 377 (1987-2001)
- Kenworth C500 (1981-2016)
- Peterbilt 567 (2014-2020)
- Peterbilt 384 (2008-2016)
- Peterbilt 365 (2008-2020)
- Kenworth T400 (2012-2021)
- Peterbilt 385 (1995-2008)
- Peterbilt 376 (1988-1992, 1994-1996, 1999)
- Peterbilt 375 (1987-1996)
- Peterbilt 379 (1990-2007)
- Peterbilt 378 (1990-2007)
- Peterbilt 357 (1990-2007)
- Kenworth W900 (1982-2021)
- Kenworth T600A (1986-2008)
- Peterbilt 387 (2000-2011)
- Kenworth T2000 (1997-2011)
MONROE 65495 Cross References
We have 32 alternatives for the 65495 by MONROE:
- GABRIEL 89451
- KENWORTH C711002
- MERITOR M89451
- MERITOR M85067
- 89451
- 65495MM
- MAE65495
- GABRIEL 85067
- POWER10 PARTS SSA-85067
- POWER10 PARTS SSA-89451
- KENWORTH c711016
- KENWORTH C711016A
- KENWORTH C716015
- PETERBILT C711016
- PETERBILT C716000
- PETERBILT C716015
- FOX COMMERCIAL TRUCK SHOCKS 98031008
- OEM C716015
- PETERBILT C711016PLUS
- SACHS NORTH AMERICA 315424
- OEM C711016A
- OEM c711016
- VOLVO / WHITE / GMC RCSA5067
- VOLVO / WHITE / GMC SA5067
- KENWORTH C711002
- OEM C716000
- GABRIEL 671794
- GABRIEL 89451
- OEM C711002
- KYB 341614
- HALDEX SA65495
- BULLDOG HD SHOCKS HD1215-0034
