MONROE 65495 Part Description
Manufacturer
Product Description
Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65495 Specifications
Product Attributes
| Compressed Length | 18.3594 IN |
| Compressed Length | 466.3 MM |
| Extended Length | 30.5 in |
| Extended Length | 774.7 MM |
| Travel Length | 12.141 in |
| Travel Length | 308.4 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS80 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 3.9/16" Sleeve OAL |
| Upper Mount Code | LS87 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173959 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65495 Cross References
| Brand | Part Number |
|---|---|
| 89451, 65495MM, MAE65495 | |
| Alliance Parts | ABPN32O900020, ABPN32G900020 |
| Automann | A85067 |
| BULLDOG HD SHOCKS | HD1215-0034 |
| Bulldog HD | HD12150034 |
| Dayton Parts | 44185067 |
| FCS | F347215, F347306, F343376, F346599, F343378, F343368, F344355, F344353, F346598, F346633, F344342, F344343, F347303, F343375 |
| FOX COMMERCIAL TRUCK SHOCKS | 98031008 |
| GABRIEL | 89451 , 85067, 671794, 89451 |
| HALDEX | SA65495 |
| KENWORTH | c711016, C711016A, C716015, C711002 |
| KENWORTH | C711002 |
| KYB | 341614, 441600, 341621, 341620 |
| MERITOR | M89451, M85067 |
| NAPA Shocks | 65495 |
| OEM | C716015, C711016A, c711016, C716000, C711002 |
| PETERBILT | C711016, C716000, C716015, C711016PLUS, C71-6015 |
| POWER10 PARTS | SSA-85067, SSA-89451 |
| Paccar Parts | C711002, C711016, C711016A, C711016PLUS, C716000, C716015 |
| Peterbilt | C711002, c711016 |
| Road Choice | SA5000, SA5067 |
| SACHS NORTH AMERICA | 315424 |
| Sachs | 315424 |
| VOLVO / WHITE / GMC | RCSA5067, SA5067 |
| Volvo GM Heavy Truck | RCSA5067, SA5067 |
| WORLD AMERICAN | WA01-89451 |
MONROE 65495 Fits Vehicles
- Kenworth W990 (2019-2024)
- Peterbilt 382 (2011-2017)
- Kenworth T800 (2001-2021)
- Peterbilt 587 (2011-2015)
- Kenworth T700 (2011-2016)
- Peterbilt 389 (2008-2024)
- Peterbilt 579 (2013-2024)
- Kenworth T880 (2014-2024)
- Kenworth T680 (2013-2024)
- Peterbilt 388 (2008-2015)
- Peterbilt 386 (2006-2016)
- Peterbilt 367 (2008-2020)
- Kenworth T660 (2008-2019)
- Peterbilt 377 (1987-2001)
- Kenworth C500 (1981-2016)
- Peterbilt 567 (2014-2024)
- Peterbilt 384 (2008-2016)
- Peterbilt 365 (2008-2020)
- Kenworth T400 (2012-2021)
- Peterbilt 385 (1995-2008)
- Peterbilt 376 (1988-1992, 1994-1996, 1999)
- Peterbilt 375 (1987-1996)
- Peterbilt 379 (1990-2007)
- Peterbilt 378 (1990-2007)
- Peterbilt 357 (1990-2007)
- Kenworth W900 (1982-2021)
- Kenworth T600A (1986-2008)
- Peterbilt 387 (2000-2011)
- Kenworth T2000 (1997-2011)
