MONROE 34694 Part Description
Manufacturer
Product Description
Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 34694 Specifications
Product Attributes
| Compressed Length | 15 IN |
| Compressed Length | 381 MM |
| Extended Length | 24.125 in |
| Extended Length | 612.8 MM |
| Travel Length | 9.125 in |
| Travel Length | 231.8 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS47 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Upper Mount Code | LS47 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Yellow |
| Cylinder Color | Yellow |
| Color | Yellow |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050786 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34694 Cross References
| Brand | Part Number |
|---|---|
| 34694MM, MAE34694 | |
| ACDELCO | 560-251 |
| ACDelco | 560251 |
| Chevrolet | 15210861, 15753519, 15753521, 19152878, 19177927, 19208627, 20906276, 20906277, 20951274, 20951275, 20951276, 20951277, 22064862, 22187161, 22187162, 22187164, 22187165, 22400057, 22400058, 22400060, 22400061, 22400062, 22400063, 22400188, 22400189, 22400246, 22400247, 22400317, 22400319, 25818491, 25880357, 25984611, 25984613, 25984618, 25984619, 88983817, 88983819, 89038653, 89038654, 89038655 |
| Duralast | TS3431422B |
| FCS | 342476, 342544 |
| FCS AUTO PARTS | 342476 |
| GABRIEL | 58930, 58412, 81930, 61642, 61675 |
| GMC | 19152878, 19177927, 19208627, 20906276, 20906277, 20951274, 20951275, 20951276, 20951277, 22064862, 22187154, 22187155, 22187159, 22187160, 22187161, 22187162, 22187164, 22187165, 22400057, 22400058, 22400060, 22400061, 22400062, 22400063, 22400188, 22400189, 22400246, 22400247, 22400317, 22400319, 25818491, 25880357, 25984611, 25984613, 25984618, 25984619, 88983816, 88983817, 88983818, 88983819, 89038654, 89038655, 89060250 |
| General Motors | 20906276, 20906277, 20951276, 20951277, 25880357, 25984611, 25984618 |
| KYB | 344384, KG54341, 565103, 344437 |
| MasterPro Shocks and Struts | GM136 |
| Monroe Shocks & Struts | 32345 |
| NAPA Proformer | SH81930 |
| NAPA Shocks | 76694 |
| OEM | 20951276, 25880357, 20951277, 20906277, 25984618, 20906276, 25984611 |
| SACHS NORTH AMERICA | 30756 |
| Sachs | 30756 |
| Sensen | 12140432 |
MONROE 34694 Fits Vehicles
- GMC Sierra 3500 Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- GMC Sierra 3500 HD (2007-2010)
- Chevrolet Silverado 3500 HD (2007-2010)
- GMC Yukon XL 2500 (2000-2013)
- GMC Sierra 3500 (2001-2006)
- Chevrolet Suburban 2500 (2000-2013)
- Chevrolet Silverado 3500 (2001-2006)
- Chevrolet Avalanche 2500 (2002-2006)
