(888) 312-8812 Login SignupCENTRIC 121.45029 C-Tek Standard Brake Rotor
Tap to view 4 more
$55.88
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 121.45029 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.45029 Specifications
Product Attributes
| Inner Bearing # [cntrc] | 412.45002 |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Standard |
| Weight [cntrc] Lbs | 15.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Hub & Rotor |
| Vane Style [cntrc] | Curved |
| Weight [cntrc] Kgs | 7.050 |
| Inner Seal # [cntrc] | 417.45017 |
| Discard Thickness | 20.000 MM |
| Discard Thickness | 0.787 IN |
| Nominal Thickness | 22.200 MM |
| Nominal Thickness | 0.874 IN |
| Stud Thread Diameter | 12.000 MM |
| Overall Height | 72.300 MM |
| Overall Height | 2.846 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Rotor Outside Diameter | 255.000 MM |
| Rotor Outside Diameter | 10.039 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.500 MM |
| Bearings Included | No |
| Center Hole Diameter | 67.000 MM |
| Center Hole Diameter | 2.638 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.575 MM |
| Stud/Lug Hole Diameter | 0.495 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Country of Origin (Primary) | CN |
| NAFTA Preference Criterion Code | B |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890048527 |
CENTRIC 121.45029 Cross References
| Brand | Part Number |
|---|---|
| 96302, 96302RGS, BD61839 | |
| N/A | 0832363, BD61839, 3201, BR3201, 121.45029, 64 74 340, 6474340, HE253325XC, 106608, 3201G, HE1333251A, HE253325X, HE253325XB, HF1333251, HF1333251A, 141637, PRT1637, 112010, 4886302, 86302, 1113, JBR388, JBR388E, D17583, 1262824, 1.2628.2.4, 25450, X50462, BR1652, 96302, 96302R, 96302RGS, DF4009, 78914029, 8914029, 78-14029, 7814029, 60080019 |
| RAYBESTOS | 96302, 96302R |
CENTRIC 121.45029 Fits Vehicles
- Mazda 929 (1988-1991)
CENTRIC 121.45029 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 121.45029 Questions & Answers
No questions yet
Be the first to ask a question about this product!
