Gates G23832-3232 - Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube
$72099
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube
Features & Benefits
- Greater power and capacity from existing equipment by replacing 2 in., 5000 psi hose assemblies
- A flexible, easier-to-route hose assembly to replace 2 in. rigid pipe on crowded equipment platforms
- A stem machined from a single piece of solid steel for greater strength and integrity
- A no-skive design requiring no special equipment and skills, reducing the risk of blow-offs or leaks
Product Attributes
| Coupling Description | GlobalSpiral MAX Pressure Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 32GSM-32FBSPORX90 |
| Thread Size | 2-11 |
| Inside Diameter | 2 IN |
| Hydraulic Hose Recommendation | Gates Extremely High Pressure Hose - EFG6K - SAE 100R15, EFG5K - SAE 100R13 |
| Nut Hex Size | 70 MM |
| Drop Length | 5.91 IN |
| Cut-Off Length | 6.4 IN |
| Length | 10.89 IN |
| Inside Diameter | 50.8 MM |
| Drop Length | 150 MM |
| Cut-Off Length | 162.5 MM |
| Length | 276.5 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| Country of Origin (Primary) | US |
| UPC | 00770075556763 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
