Centric 120.66078 - Centric Premium Brake Rotor
$7849
MSRP: $101.80
Save: $23.31
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] In | 6.283 |
| Weight [cntrc] Lbs | 20.900 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 159.600 |
| OEM Vane Count [cntrc] | 47 |
| Weight [cntrc] Kgs | 9.480 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.984 IN |
| Discard Thickness | 25.000 MM |
| Nominal Thickness | 1.063 IN |
| Nominal Thickness | 27.000 MM |
| Hat Finish | Coated |
| Overall Height | 61.000 MM |
| Overall Height | 2.402 IN |
| Outside Diameter | 310.000 MM |
| Outside Diameter | 12.205 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.795 IN |
| Center Hole Diameter | 71.000 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 15.600 MM |
| Stud/Lug Hole Diameter | 0.614 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890323235 |
Part Interchanges
CENTRIC 120.66078 Cross Reference
We have 3 alternatives for the 120.66078 by CENTRIC:
Fits Vehicles
- GMC Canyon (2015-2020)
- Chevrolet Colorado (2015-2020)
