MONROE part description

Product Description

Magnum Steering Damper

Features & Benefits

  • REDUCES VIBRATION -- Ideal for trucks, vans, SUVs, and CUVs, it helps reduce vibrations that travel through the steering system before they get to the driver to improve control and cut down on driver fatigue in all driving conditions
  • CONSISTENT PERFORMANCE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • STRONG AND DURABLE -- Sintered iron piston and .50-in. nitrocarburized piston rod for enhanced durability and long service life
  • EXCEPTIONAL HANDLING -- Full displaced valving delivers better valving range on both compression and extension cycles for consistent performance
  • LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas without excessive wear or friction
  • MOUNTS HORIZONATALLY -- Micro-cellular gas design allows the unit to be mounted horizontally without impacting performance for improved steering control

Product Attributes

Compressed Length 12.5000 IN
Extended Length 20.6250 in
Shock Absorber Body End Measuring Point Center of Loop
Travel Length 8.1250 in
Body Diameter 1.8600 IN
Lower Mount Type Loop Bushing And Sleeve Mount - 1/2" Sleeve ID X 38.1mm Sleeve OAL
Lower Mount Code LS35
Upper Mount Type Loop Bushing Mount - 5/8" Bushing ID X 1-5/16" Bushing OAL
Upper Mount Code L1
Dust Shield Included No
Dust Shield Material N/A
Gas Charged No
Parts Pack(s) P01368
Shock Absorber Rod End Measuring Point Center of Loop
Part Description Steering Damper

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708949900
Harmonized Tariff Code (Schedule B) 8708947550
Harmonized Tariff Code (HTS) 8708947550
UPC 00048598015518
VMRS Code 015004022
UNSPSC 25174202

Part Interchanges

MONROE SC2963 Cross Reference

We have 2 alternatives for the SC2963 by MONROE:

Fits Vehicles

  • GMC Sierra 3500 Classic (2007)
  • Chevrolet Silverado 2500 HD Classic (2007)
  • GMC Sierra 2500 HD Classic (2007)
  • Chevrolet Silverado 3500 Classic (2007)
  • GMC Sierra 3500 HD (2007-2010)
  • Chevrolet Silverado 3500 HD (2007-2010)
  • Hummer H2 (2003-2009)
  • GMC Yukon XL 2500 (2000-2010)
  • GMC Sierra 3500 (2001-2006)
  • GMC Sierra 2500 HD (2001-2010)
  • Chevrolet Suburban 2500 (2000-2010)
  • Chevrolet Silverado 3500 (2001-2006)
  • Chevrolet Silverado 2500 HD (2001-2010)
  • Chevrolet Avalanche 2500 (2002-2006)
