(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | S5 |
| Upper Mount Code | S5 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Internal Construction Type | Twin Tube |
| Adjustable Damping | No |
| Color | Black |
| Finish | Painted |
| Shock Absorber Bore Size | 35 MM |
| Foam Cell Design | No |
| Shaft Diameter | 16 MM |
| Compressed Length | 14 IN |
| Dust Shield Material | Metal |
| Extended Length | 24.125 in |
| Gas Charged | Yes |
| Lower Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Parts Pack(s) | (2) P01303 |
| Travel Length | 10.125 in |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Compressed Length | 355.6 MM |
| Extended Length | 612.8 MM |
| Travel Length | 257.2 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Base of Stem |
| Adjustable Damping | No |
| Lower Mount Type | Stem |
| Lower Mount Code | S5 |
| Upper Mount Code | S5 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598074263 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
