(888) 312-8812 Login SignupMONROE 65478 Magnum Rear; Front Suspension Shock Absorber
Tap to view 3 more
MSRP: $270.57
$9849
Save $172.08
Limited availability at this price!
In Stock
Get it by Thursday, Jul 9
MONROE 65478 Part Description
Manufacturer
Product Description
Magnum Rear; Front Suspension Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65478 Specifications
Product Attributes
| Compressed Length | 15.02 IN |
| Compressed Length | 381.5 MM |
| Extended Length | 23.75 in |
| Extended Length | 603.3 MM |
| Travel Length | 8.73 in |
| Travel Length | 221.7 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Upper Mount Code | LS54 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173782 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65478 Cross References
| Brand | Part Number |
|---|---|
| 65478MM, MAE65478 | |
| BILSTEIN | B462093 |
| BULLDOG HD SHOCKS | HD1215-0108, HD1215-0115 |
| Bilstein | 24020930, B451868, F4B462093M1 |
| Blue Bird | 15222 |
| Bulldog HD | HD12150115 |
| CHEVROLET | 12474916, 15012820 |
| Dayton Parts | 441850585478 |
| FCS | F347198, F347315 |
| FORETRAVEL | B451868 |
| FREIGHTLINER | 1615676000, 16-15676-000 |
| GABRIEL | 85058, 89440, 85030 |
| GM | 15012820, 12474916 |
| Gabriel | 89431 |
| General Motors | 15012820, 12474916 |
| Gold Shock Absorber | 5001267, 8180172, 9180193 |
| HALDEX | SA65478 |
| HENDRICKSON | 59483000, 579054, 594830, 606655, 60665005, 606707, 598514, 4790226, 6066560, 60670007 |
| Hendrickson | 60670007L |
| International | 2029200C91, 4070336C1, 4164155C1 |
| International Harvester (IHC) | 2029200C91 |
| KONI | 881704 |
| MERITOR | M85030, M89440 |
| MONROE VINTAGE | 557027 |
| Monroe Shocks & Struts | 557027 |
| NAPA Shocks | 65478 |
| NEWAY | 90045277 |
| OEM | 2029200C91, 15222, W8007000, 1615676000, 60665005, 60670007, 59483000 |
| Pierce Mfg Inc | 405348 |
| ROADMASTER | 90045277 |
| SACHS NORTH AMERICA | 315398, 471700000459, 410068, 315613, 471700000436, 311635 |
| SAFARI MOTOR COACH | B462093 |
| Sachs | 315398, 471700000459, 410068, 315613, 471700000436, 311635 |
| Workhorse | W8007000 |
MONROE 65478 Fits Vehicles
- International HX520 (2018-2026)
- International WorkStar 7600 (2008-2014, 2017-2019)
- International 7600 (2003-2007, 2009-2017)
- International 7500 (2002-2020)
- International 7400 (2002-2020)
- Western Star 6900XD (2002-2016, 2018-2019, 2022-2023)
- International 9800 SBA (1996-1999)
