GasSLX Shocks
GasSLX Shocks – Adjustable Commercial Truck and Trailer Shocks (89000 series) - The three position GasSLX™ adjustable shocks absorbers by Gabriel® allow you to choose from one of three settings – Firm, Regular and Extra Firm – to match different applications. The GasSLX shock incorporates a gas cell design, creating a physical barrier between gas and fluid, preventing aeration which can cause fade, or reduction in damping force. This gas cell technology is a full-life feature and is better suited for longer-life commercial vehicle applications. And like all Gabriel shocks and struts, GasSLX shocks feature a super-finished chrome piston rod for superior corrosion resistance and a leak-proof piston seal which extends product life. Advanced gas cell technology improves gas retention and provides more consistent high temperature operation. Unique pressurized piston seal design reduces force-velocity variabilities and self compensates for wear.
| Core Color | Y |
| Dust Tube Material | Steel |
| Features/Benefits 2 | Three settings for adjustability: OE ride (firm), increased handling & control (extra firm), or maximum driver comfort (regular) |
| HD Mounting Code Guide.pdf | https://gabriel.com/sites/default/files/2025_HD_Mounting_Code_Guide.pdf |
| Recoil Cutoff | YES |
| Accessory Kit # | n/a |
| Collapsed Length (in) | 15.31 |
| Extended Length (in) | 23.9 |
| Features/Benefits 3 | Specially formulated high temp. fluid & multi-lip Viton rod seal reduces friction & wear, even in extreme operating conditions |
| Lower Mount Code | ES36 |
| Stroke (in) | 8.59 |
| Adjustable Damping | YES |
| Compression (lb) | 561 |
| External Diameter Illustration | G |
| Features/Benefits 4 | Gas Cell design is superior to gas-charged shocks; gas cell double seals gas from fluid for optimum performance |
| Package Contents | 1 Shock |
| Upper Mount Code | ES36 |
| Bore | 1-5/8" |
| Dust Tube | YES |
| Features/Benefits 1 | Top of the line, adjustable, heavy-duty gas shock for class 7 – 8 vehicles, school buses and transit buses |
| Features/Benefits 5 | Chromed piston rod to inhibit corrosion, ensure proper seal lubrication and provide a more consistent wear surface |
| Rebound (lb) | 1498‡ |
| Weight (lbs) | 7.9 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| MSDS Sheet Number | ARP002 / RC001 |
| Country of Origin (Primary) | MX |
| UPC | 00043645924218 |
| VMRS Code | 016003016 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| GBL89440 | |
| BULL DOG | HD1215-0157 |
| BULLDOG HD SHOCKS | HD1215-0157 |
| BWP-NSI | SH89440 |
| Bulldog | HD1215-0157 |
| GABRIEL | 85030 |
| HALDEX | SA66969 |
| Hendrickson | 680463 |
| Holland | 671923, 90045420 |
| MAECO | 70650 |
| MERITOR | M89440 |
| MONROE | 65478, 65421 |
| Monroe Shocks & Struts | 70650 |
| N/A | 85030, 88-1422, 88-1704, CAX-969, AX-79A, 507202C1, AMS600172, 2029200C91, 2015557C1, 1677707C1, AMS650429, AMS660157, AMS650108, AMS650478, F6HT18045GC, F6HT-18045-GB, F6HT18045GB, F6HT-18045-GC, E85030, 508-26, 508-29, B46-1594, B462151, 0346-SS5, B462385, B461732, B461594, 0346SS5, B462502, M85030, 40-6967, 406967, 5170500620, 517-05006-20, 58122-MB, 471700000436, 90045813, 90045532, 90045504, 90045277, 471700000459, 1668722, 16787, 70652, ABP N32 O900087, ABP N32 G900087, F347193, 22065251, KG6002A, 65454, 65429, 65108, 315613, 311635, 316840, 410068, 316815, 317936, 316320, 20125-01, 2012501, FLL85030-07I, FLL8503007I, 3199938, 1093180, 3919938, 20707753, 441 - 85030, 9180193, HD1215-0108, 40-3135, 01722214, UEY 1124-001, UEY 1124001, B46-1732, 24-017329, F4-B46-1732-H1, 47902-18, S2218, S20886, A2218, 665405, S-2218, 4790218, S-20886, A-2218, A-20886, A20886, 728632, PROSH85030, 471700000460, 89440, 08947207I |
| PRT | 925107 |
| Reyco Granning | 20126-01, 2012601 |
| TRP | 89440GSK |
| Tuthill Transfer | 20126-01, 2012601 |
