MONROE 5794 Part Description
Manufacturer
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 5794 Specifications
Product Attributes
| Compressed Length | 14.38 IN |
| Compressed Length | 365.3 MM |
| Extended Length | 24.2 in |
| Extended Length | 614.7 MM |
| Travel Length | 9.82 in |
| Travel Length | 249.4 MM |
| Lower Mount Type | Special Mount |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | SPEC |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01136 |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598721648 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5794 Cross References
| Brand | Part Number |
|---|---|
| 5794ST, GD9Z17682KCPTM | |
| ACDelco | 503673 |
| AUTOZONE | TS33-34922B |
| AutoZone | TS3334922B |
| Chevrolet | 96408661, 96408662, 96408663, 96408664, 96408735, 96653231, 96653232, 96653233, 96653234, 96980824, 96980825, 96980826, 96980827, 96980828, 96980829 |
| Duralast | TS3334922B |
| FCS | 341612 |
| FCS AUTO PARTS | 341612 |
| GABRIEL | G51747 |
| GMC | 96980829 |
| General Motors | 96980829 |
| KYB | 343423 |
| KYB AMERICA LLC. | 343423 |
| MasterPro Shocks and Struts | GM166 |
| Monroe Shocks & Struts | 210110 |
| NAPA Shocks | 5794, 94397, NS5794 |
| OEM | 96980829 |
| Pontiac | 96653231, 96653232, 96653233, 96653234, 96653235, 96980820, 96980821, 96980822, 96980823, 96980824, 96980825, 96980826, 96980827, 96980828, 96980829 |
| SENSEN | 12130345 |
| TVA | TVA42115310 |
| Top Quality | 785794 |
| UNITY AUTOMOTIVE | 4-11403-251190-001, 2-251190-001, 251190 |
| Unity | 251190 |
MONROE 5794 Fits Vehicles
- Pontiac G3 (2007-2010)
- Chevrolet Aveo5 (2007-2011)
- Pontiac Wave (2005-2008)
- Chevrolet Aveo (2004-2018)
