MONROE 66884 Magnum Amortisseur

★★★★★ (0)
Monroe 66884 Suspension Shock Absorber Magnum Amortisseur
MONROE
Tap to view 11 more
Monroe 66884 Suspension Shock Absorber Magnum Amortisseur

$55.99

Limited availability at this price!

In Stock

Get as soon as Tuesday, Nov 24
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

MONROE 66884 Part Description

Manufacturer

MONROE

Product Description

Magnum Rear Suspension Shock Absorber

Features & Benefits

  • INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
  • FOR HARDWORKING COMMERCIAL VEHICLES   -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 66884 Specifications

Product Attributes

Compressed Length17.188 IN
Compressed Length436.6 MM
Extended Length27.953 in
Extended Length710 MM
Travel Length10.765 in
Travel Length273.4 MM
Lower Mount TypeLoop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Lower Mount TypeLoop (Eyelet) Bushing and Sleeve
Lower Mount CodeLS54
Upper Mount TypeLoop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Upper Mount CodeLS54
Shock Absorber Rod End Measuring PointCenter of Loop
Shock Absorber Body End Measuring PointCenter of Loop
Gas ChargedYes
Mounting Hardware IncludedNo
Parts Pack(s)None
Body ColorBlack
Cylinder ColorBlack
ColorBlack
FinishPainted
Cylinder FinishPainted
Dust Shield IncludedYes
Dust Shield Diameter57.4 MM
Dust Shield Diameter2.26 IN
Dust Shield MaterialMetal
Shock Absorber Bore Size35 MM
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutYes
Internal Construction TypeTwin Tube
Grade TypePremium
Adjustable DampingNo
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber
Shaft Diameter16 MM

Additional Information

MSDS Sheet Number01164
Country of Origin (Primary)US
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598075444
VMRS Code016008003
UNSPSC25172011

MONROE 66884 Cross References

BrandPart Number
83201, 66884MM, MAE66884
BATCO1083201, 1083202
BINKLEYXBSPN05336, 6898
BLUE BIRD1316546
BUILT RITE31806100
BULLDOG HD SHOCKSHD1214-0532
Bulldog HDHD12140532
CASCADE TRAILER1201
CHEVROLET3919917
DEXTER CO1816501
Dayton Parts44183125
Dexter1816501
EUCLIDM83125, E85006, E83201
GABRIEL83125, 59031, 727601, 83201, 638312, 665465, 728618
GENERAL TRAILERCC514, 1201, 650147, CC512
GM3919917
GREAT DANE TRAILERS1816501
General Motors3919917
Gold Shock Absorber8150240, 8160091, 9160527
HALDEXSA66884
HENDRICKSONA2471
INTERNATIONALAMS600114, AMS660114
IVECOM0044012
KYB345616
KYB AMERICA LLC.345616
MACK14QK410M, 25625234, 660114MT, 600114MT
MACK 14QK410M
MERITORM83125
MONROE VINTAGE660114, 660244, 66898, 661114, 6898, 6045, 601114, 12608
MOTORCRAFTCAX898
Monroe Shocks & Struts12608, 601114, 6045, 660114, 660244, 661114, 66898, 6898
NAPA Shocks66884
NEWAYAR1008, 90044687, 57366898, 90044679, 57306898, 90044680, 90044012
NUTURN/LELANDL57644
OEM14QK410M, 11604
PEERLESS7261, 1201
RAMERIZ TRAILER1816501
REYCO GRANNING1816501, 1982401, 1682401
RIDEWELL CORPAS546B
SACHS NORTH AMERICA510001, 290465, 410021
Sachs510001, 290465, 410021
TORQUE PARTSTR83125
TRAIL MOBILE90044625, 434241, 436137, 438015
TURNER / QUICK LIFT CORP.A2471
Trailmobile434241, 436137, 438015, 90044625
TurnerA2471
VOLVO / WHITE / GMCSA3125, 3919917, RCSA3125
Volvo GM Heavy Truck3919917, RCSA3125, SA3125
WATSON & CHALIN11604

MONROE 66884 Fits Vehicles

  • Mack CH (1989-2005)
  • Blue Bird Commercial Bus (1992-2007)
  • Blue Bird TC2000 (1989-2004)
