(888) 312-8812 Login SignupMONROE 34692 Gas-Magnum Rear Suspension Shock Absorber
Tap to view 11 more
MSRP: $102.39
$5799
Save $44.40
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
MONROE 34692 Part Description
Manufacturer
Product Description
Gas-Magnum Rear Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 34692 Specifications
Product Attributes
| Compressed Length | 14.75 IN |
| Compressed Length | 374.7 MM |
| Extended Length | 23.5 in |
| Extended Length | 596.9 MM |
| Travel Length | 8.75 in |
| Travel Length | 222.3 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS47 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Upper Mount Code | LS47 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Yellow |
| Cylinder Color | Yellow |
| Color | Yellow |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050762 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34692 Cross References
| Brand | Part Number |
|---|---|
| 34692MM, FT4Z5810177DC | |
| ACDelco | 540433, 540532, 560217 |
| Chevrolet | 12476113, 12476445, 12477516, 12477517, 12477645, 12477646, 12477658, 12477659, 12477660, 12477661, 12477738, 15057972, 15770188, 15770189, 19300045, 19300047, 22187151, 22187152, 22187154, 22187155, 22187156, 22187157, 22187158, 22187159, 22187160, 22400056, 22400059, 22400884, 22400885, 25871225, 88934736, 88965472, 88983816, 88983818, 89040177 |
| Duralast | TS3431422B |
| FCS | 342476 |
| FCS AUTO PARTS | 342476 |
| GABRIEL | 58930, 61675 |
| GMC | 12476113, 12476445, 12477516, 12477517, 12477645, 12477646, 12477658, 12477659, 12477660, 12477661, 12477738, 15057972, 15770188, 15770189, 19300045, 19300046, 19300047, 22187151, 22187152, 22187154, 22187155, 22187156, 22187157, 22187158, 22187159, 22187160, 22400056, 22400059, 25871225, 88934736, 88965472, 88983816, 88983818, 89040177, 89060250 |
| KYB | 344384, KG54341, 565103, 565033, KG54101, 565034, SR2003, 565074, 344262, 344273, KG54100, SR2004 |
| MasterPro Shocks and Struts | GM102 |
| Monroe Shocks & Struts | 210253, 37166, 911166, 32348 |
| NAPA Proformer | SH81930 |
| NAPA Shocks | 76692 |
| Rancho | RS5262, RS55262 |
| SACHS NORTH AMERICA | 930041 |
| Sachs | 930041 |
| Sensen | 12140127 |
MONROE 34692 Fits Vehicles
- GMC Yukon XL 1500 (2000-2006)
- GMC Yukon (2000-2006)
- Chevrolet Tahoe (2000-2006)
- Chevrolet Suburban 1500 (2000-2006)
