BENDIX 801591 Part Description
Manufacturer
Product Description
Relay Valve
Features & Benefits
- Operates with a 4.0 psi crack pressure in this configuration
- Includes a loose mounting bracket for the intended service setup
- Two supply inlets feed a four-delivery relay layout for grouped chamber lines
- Delivery layout splits two ports horizontally and two vertically
Bendix Air Brake Relay Valve
A two-supply, four-delivery body configuration gives the Bendix Air Brake Relay Valve a compact but clearly defined plumbing layout. Two delivery ports sit horizontally and two vertically, giving installers more than one line approach around the valve body. The Bendix 801591 uses a 4.0 psi crack pressure and comes with the mounting bracket loose in the box. These layout and service details help distinguish it from relay valves with different port counts or mounting arrangements.
BENDIX 801591 Specifications
Product Attributes
| Balance / Primary Service Port | 1/8-27 NPT (with Cover) |
| Body Configuration | 2 SUP / 4 DEL (2H + 2V) |
| Cautionary Note(s) | Not applicable to this part |
| Control / Secondary Service Port | 1/4-18 NPT |
| Control Port Orientation (CW from Front Face) | 90Adeg |
| Crack Pressure | 4.0 PSI |
| Delivery Port 1 | 1/2-14 NPT |
| Delivery Port 2 | 1/2-14 NPT |
| Delivery Port 3 | 3/8-18 NPT |
| Delivery Port 4 | 3/8-18 NPT |
| Delivery Port 5 | Not applicable to this part |
| Delivery Port 6 | Not applicable to this part |
| Delivery Port 7 | Not applicable to this part |
| Delivery Port 8 | Not applicable to this part |
| Exhaust Port | Dust Shield |
| Internal Supply Passage to Cover | Not applicable to this part |
| Market Indicator | Aftermarket New |
| Maximum Operating Temperature | 200 AdegF (93 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | 5/16-18 UNC-2A Stud (2x) |
| Mounting Bracket Direction | Not applicable to this part |
| Mounting Bracket Location | Loose in Box |
| Mounting Orientation (CW from Front Face) | Not applicable to this part |
| Supply Port 1 | 1/2-14 NPT |
| Supply Port 2 | 1/2-14 NPT |
| TMC Washer | RV040 |
Additional Information
| Country of Origin (Primary) | MX |
| UPC | 04068078304433 |
| VMRS Code | 013010009 |
BENDIX 801591 Cross References
| Brand | Part Number |
|---|---|
| BW801591 | |
| N/A | K047630, 102802N |
