(888) 312-8812 Login SignupBENDIX K023171 Air Brake Pressure Protection Valve - 1/4-18 NPT Ports, 221°F Max Temp
Tap to view 4 more
$51399
7 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
BENDIX K023171 Part Description
Manufacturer
Product Description
Tractor Protection Valve
Courtesy of Bendix – All rights reserved
BENDIX K023171 Specifications
Product Attributes
| Gross Weight | 1.120 KG |
| Market Indicator | Aftermarket New |
| Net Weight | 1.120 KG |
| Auxiliary Supply Port | Not applicable to this part |
| Exhaust Port | Dust Shield |
| Maximum Operating Temperature | 221 AdegF (105 AdegC) |
| Minimum Operating Temperature | -40 AdegF (-40 AdegC) |
| Mounting | 5/16-18 UNC-2B with .62 MIN full thread (8x) |
| Mounting Type | Cab / Chassis |
| Service Line Shut-Off Pressure | 10 PSI (MIN) |
| Stop Light Switch Port | 1/4-18 NPT |
| Stop Light Switch Port (Firewall) | Not applicable to this part |
| Tractor Control Port (Primary) | 3/8-18 NPT |
| Tractor Control Port (Secondary) | 3/8-18 NPT |
| Tractor Protection Port | 3/8-18 NPT |
| Tractor Protection Port (Firewall) | Not applicable to this part |
| Tractor Service Port | Not applicable to this part |
| Trailer Control Port | 3/8-18 NPT |
| Trailer Service Port | 1/2-14 NPT |
| Trailer Service Quick Release | Yes |
| Trailer Supply Port | 1/2-14 NPT |
| Trailer Supply Quick Release | Not applicable to this part |
| Vent | Yes |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (HTS) | 8481200070 |
| UPC | 04068078224267 |
| VMRS Code | 013010016 |
BENDIX K023171 Customer Reviews
No reviews yet
Be the first to review this product!
BENDIX K023171 Manufacturer Information
A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.
