APSCO part description

Hydraulic Cab Air Control Valve, 4-Way, Push/Pull, Single Spool, 2-Position

APSCO Push-Pull Valve

Engineered using the latest technology, the APSCO push-pull valve offers maximum efficiency and reliability. It is a direct replacement for the existing part as it is made to meet or exceed OE specifications.

Features & Benefits
  • Manufactured using modern tooling to ensure durability and long service life
  • A 4-way 2-POS push-pull valve that is rigorously tested to ensure the highest quality
  • Installs fast and easy just like the factory unit
  • Delivers reliable performance at an affordable price

Product Description

Air Control Valve

Product Attributes

Action Push/Pull
Cylinder Type Double Acting
Depth 1 IN
Length 2 in
Mounting Type Threaded 10-32 UNF Vertical, Thru Holes Horizontal
Part Type Air Control Valve
Port 1 Diameter 1/8 IN
Supply 130
Width 2 in
Length 2 in.
Width 2 in.
Mounting Hole Quantity 4
Depth 1 in.
Operating Range 0 to 150 PSI
Supply Port Diameter 1/8-27 NPT
Outlet Port Thread Diameter 1/8-27 NPT
Exhaust Port Diameter 1/4 in.

APSCO® is a proud manufacturer of pneumatic cylinders, controls, and valves for the mobile, truck equipment, and automotive industries since 1964. The company continuously evolves to meet industry challenges and the changing needs of customers. But providing innovative solutions need not compromise quality, and that's APSCO's commitment since day one. The company makes use of the highest quality materials and the latest technology in manufacturing its products. And it rigorously tests them before shipment to ensure only safe and reliable APSCO products reach their customers. These stringent manufacturing processes and tests have earned them an ISO 9001:2001-certified company, beginning in 2004.
