APSCO part description

CYL 3.5 X 4 DA 16NS BR PK PORTS ON SIDE BORE = 3.5 STROKE = 4.0 RETRACTED PIN TO PIN = 13.0 EXTENDED PIN TO PIN = 17.0 EXTENSION FORCE @ 100PSI = 962 LBS RETRACT FORCE @ 100PSI = 884 LBS

Product Attributes

Application Tailgate Latch
Bore Diameter 3.5 in.
Stroke Length 4 in.
Cylinder Type Double Acting
Mounting Type Bracket End
Pin Kit Included Yes
Seal Kit Part No. SK-3037
Force Rating 962 LB Force at 100 PSI
Push Rod Thread Diameter 1"-14
Port Diameter 1/4 in. NPT
Port Quantity 2
Clevis Pin Diameter 3/4 in.
Bracket Length 16 in.

APSCO® is a proud manufacturer of pneumatic cylinders, controls, and valves for the mobile, truck equipment, and automotive industries since 1964. The company continuously evolves to meet industry challenges and the changing needs of customers. But providing innovative solutions need not compromise quality, and that's APSCO's commitment since day one. The company makes use of the highest quality materials and the latest technology in manufacturing its products. And it rigorously tests them before shipment to ensure only safe and reliable APSCO products reach their customers. These stringent manufacturing processes and tests have earned them an ISO 9001:2001-certified company, beginning in 2004.
