CONMET 10082218 Drum Brake and Hub Assembly - 13,000 lbs. Rating, Iron Hub, 3.06 in. Stud, Steel Wheels

Manufacturer

CONMET

Product Description

Iron PreSet R Drive

Features & Benefits

• 13,000 lb rated iron PreSet hub assembly
• Integrated brake drum supplied as one unit
• 3.06-inch studs configured for steel wheel setups
• Factory-set spacer system eliminates manual bearing adjustment

ConMet Drum Brake and Hub Assembly

The ConMet Drum Brake and Hub Assembly is a 13,000 lb rated iron PreSet hub supplied with the brake drum mounted as a single integrated unit. Because the drum is installed to the hub during manufacturing, the mounting surfaces and drum position are set before the assembly reaches the shop. The PreSet design incorporates an internal spacer system that establishes bearing setting at build time, eliminating the need for manual bearing adjustment during installation. This configuration uses 3.06-inch studs for steel wheel applications, matching common drive axle setups that require that stud length. By supplying the drum and hub together with the PreSet bearing system already established, the ConMet 10082218 assembly helps maintain the original wheel-end setup without pressing components together separately.
