(888) 312-8812 Login SignupOutboard Mount Wheel Hub with 11.25" Bolt Circle and M22 Stud Thread
The Webb Wheel Hub carries dual aluminum wheels on a hub-piloted 2343-series assembly with the brake drum mounted outboard. It uses a 10-stud layout with Webb 101160 wheel studs at a 3.94-inch standout, so replacement studs and wheel nuts install the same way they did on the original hub. Built with a direct-machined ABS ring, the Webb 23431--5T keeps the wheel-speed signal working without a separate tone ring to transfer. Outboard drums come off without pulling the hub, which shortens brake service and keeps the truck on schedule.
HUB PILOT ALUM WHEEL
| Bolt Circle Diameter (in) | 11.25 |
| ABS | Yes |
| Bolt Hole Quantity | 10 |
| Inner Cup | HM518410 |
| INNER CONE | HM518445 |
| OUTER CONE | HM518445 |
| Drum/Rotor | Drum |
| Mount | Outboard |
| Disc/Spoke Wheel | Disc |
| Overall Depth (in) | 8.15 |
| Wheel Stud Thread | M22 |
| Outer Cup | HM518410 |
| Description | 10 Stud Hub w/11.25 (285.75MM) Dia. Bolt Circle. Bolt-on Hubcap. Uses Outboard Drum - (M22 x 1.5) Serrated Stud |
| Application | Trailer |
| Mount Type | Flange Nut |
| Stud Quantity | 10 |
| ABS Ready | Direct Machined ABS |
| Material | Cast |
| Brand | Part Number |
|---|---|
| NAVISTAR | FLTHUBPALW |
| WALTHER EMC | 10-00161-101 |
Be the first to review this product!
In business since 1946, Webb® has been a trusted brand for high-quality brake and wheel hub components in the heavy duty transportation industry. The company maintains an extensive catalog of OEM and aftermarket brake drums, brake rotors and calipers, and wheel hubs for Class 6, 7, and 8 trucks and heavy duty trailers. Each Webb product is made of premium materials and engineered for reduced weight without compromising structural strength or balance. All parts are also manufactured using the latest innovations, including advanced wear indicators and cool running vent technology to help minimize wear and make maintenance and repairs easier. Combined with a first-class customer service and after-sales support, customers can count on Webb products to keep their trucks running safely and smoothly for years to come.
