DAYCO part description

Product Description

POLY RIB BELT, DAYCO

Product Attributes

Rib Quantity 4
Top Width .54 in
Effective Length 0 in
Effective Length 0 mm
Outside Circumference 0 in
Outside Circumference 0 mm
Free Length 30.2 in
Free Length 767.080 mm
Rib Profile Straight Rib
Material EPDM4
Cross Section K-Section
Rib Depth Standard
Color Black
Standards SAE J1459
Minimum Operating Temperature -42.7 C
Maximum Operating Temperature 100 C
Minimum Operating Temperature -45 F
Maximum Operating Temperature 212 F
Notes Dayco ela™ (elastic) belts are shorter than the installed length. When installed, this belt has internal elasticity which maintains proper tension and load carrying capacity over the life of the belt.

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 4010313000
UPC 00036687907981

Fits Vehicles

  • BMW M6 Gran Coupe (2014-2019)
  • BMW M6 (2012-2018)
  • BMW M5 (2013-2016)
