(888) 312-8812 Login SignupMONROE 5504 OESpectrum Suspension Shock Absorber
Tap to view 5 more
MSRP: $77.68
$4999
Save $27.69
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
MONROE 5504 Part Description
Manufacturer
Product Description
OESpectrum Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 5504 Specifications
Product Attributes
| Lower Mount Code | LS27 |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 18.36 IN |
| Extended Length | 22.05 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.9/16" Sleeve OAL |
| Parts Pack(s) | P01744 |
| Travel Length | 3.76 in |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Compressed Length | 466.3 MM |
| Extended Length | 560.1 MM |
| Travel Length | 95.5 MM |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS27 |
| Upper Mount Code | S4 |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598164568 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5504 Cross References
| Brand | Part Number |
|---|---|
| FCS | 341962 |
| FCS AUTO PARTS | 341962 |
| GABRIEL | G51807 |
| Honda | 51605SNAA03, 51605SNAA13, 51605SNCA02, 51605SNFA01, 51605SNXA01, 51605SVAA03, 51605SVAA04, 51605SVBA03, 51605SVBA04, 51606SNAA03, 51606SNAA13, 51606SNCA02, 51606SNFA01, 51606SNXA01, 51606SVAA03, 51606SVAA04, 51606SVBA03, 51606SVBA04, 52610SNCA02, 52610SNEA03, 52610SNFA01, 52610SNXA01, 52610SNXA02, 52610SVAA03, 52610SVAA04, 52610SVBA04, 52610SVBA05, 58610SVBA050M1 |
| KYB | 348023, 343460 |
| MasterPro Shocks and Struts | HN099 |
| Monroe Shocks & Struts | 210001 |
| NAPA Shocks | 5504, NS5504 |
| OEM | 58610SVBA050M1, 52610SVBA05 |
| SENSEN | 1213-0594 |
| Sensen | 12130594 |
| Top Quality | 785504 |
MONROE 5504 Fits Vehicles
- Honda Civic (2006-2011)
MONROE 5504 Customer Reviews
No reviews yet
Be the first to review this product!
MONROE 5504 Questions & Answers
No questions yet
Be the first to ask a question about this product!
