MOOG 5549 Part Description
Manufacturer
Product Description
Shock Absorber
Application Summary
2016-2022 Chevrolet Spark (Rear) (Qualifier: Recommended OE Application -Specific Replacement)
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
Moog Rear Coil Springs OE comparable -MOOG COIL SPRINGS, SOLD AS PAIR -- Constant Rate Springs, High Quality Direct Fit OEM Replacement Coil Springs, Made From Heat-Treated Alloy Steel For A Full Coil Rebound And Sagging Resistance, Return Ride Height And Body Sway To Original Performance Levels, Restore Vehicle Handling, Use A Premium Urethane Tube That Lasts Much LongerRear
MOOG 5549 Specifications
Product Attributes
| Compressed Length | 14.17 IN |
| Travel Length | 5.17 in |
| Extended Length | 19.34 in |
| Gas Charged | Yes |
| Body Diameter | 1.519 IN |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Upper Mount Code | S15 |
| Lower Mount Code | LS5 |
| Hydraulic Lockout | No |
| Internal Rebound Bumper | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 10MM Sleeve ID X 1.7/16" Sleeve OAL |
| Part Description | Shock Absorber |
| Parts Pack(s) | None |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X M10 Thread Pitch |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801300 |
| Harmonized Tariff Code (HTS) | 8708801300 |
| MSDS Sheet Number | 01164 |
| UPC | 00048598225757 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MOOG 5549 Cross References
| Brand | Part Number |
|---|---|
| 080066119410 | |
| ACDelco | 45H2062 |
| Centric Parts | 630.62030 |
| Chevrolet | 42402330, 42504999 |
| Duralast | RCS5549S |
| FCS | 346462 |
| General Motors | 482075, 482082, 482083, 482089, 482090, 485110 |
| KYB | 3430069 |
| Mcquay-Norris | RCS5549S |
| Mevotech | SMS5549 |
| Monroe Shocks & Struts | U5549D |
| NAPA | 277-3199 |
| NAPA Shocks | 5549 |
| PM Auto | PM6001536 |
| Perfect Circle | 277-2087, 277-3199 |
| Raybestos Brakes | 589-1062 |
| Sealed Power | 831-5549 |
| TRW | CS5549 |
| TRW Steering and Suspension Parts | CS5549 |
MOOG 5549 Fits Vehicles
- Pontiac Parisienne (1976)
- Oldsmobile 98 (1971-1972)
- Chevrolet Townsman (1972)
- Chevrolet Brookwood (1972)
- Chevrolet Biscayne (1971-1972)
- Buick Estate Wagon (1972-1974)
- Buick Electra (1971-1974)
- Buick Centurion (1973)
- Pontiac Grandville (1974-1975)
- Pontiac Grand Safari (1974-1976)
- Pontiac Catalina (1976)
- Pontiac Bonneville (1974-1976)
- Oldsmobile Delta 88 (1971-1972, 1974-1976)
- Oldsmobile Custom Cruiser (1974-1976)
- Chevrolet Impala (1971-1976)
- Chevrolet Caprice (1971-1976)
- Chevrolet Bel Air (1971-1975)
- Buick LeSabre (1973, 1975-1976)
