MONROE 66602 Magnum Suspension Shock Absorber

MSRP: $61.96

$54.99

Save $6.97

Limited availability at this price!

In Stock

Get it by Monday, Feb 2
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

MONROE 66602 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES   -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 66602 Specifications

Product Attributes

Lower Mount Code L1
Upper Mount Code S4
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 12.5 IN
Dust Shield Material Metal
Extended Length 20.875 in
Gas Charged Yes
Lower Mount Type Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL
Parts Pack(s) P01134
Travel Length 8.375 in
Upper Mount Type Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Compressed Length 317.5 MM
Extended Length 530.2 MM
Travel Length 212.7 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598074577
VMRS Code 016008003
UNSPSC 25172011

MONROE 66602 Cross References

BrandPart Number
66602MM, MAE66602
BULLDOG HD SHOCKSHD1213-0708
Bulldog HDHD12130708
GABRIELG63610, G60164
HALDEXSA66602
INTERNATIONALAMS660161, 56101Z5011
KYBKG5463
Koni301366
MACK660161MT
MERITORM83161, MG60164
MITSUBISHI FUSOMC826268
MONROE VINTAGE34602, 660161, 76602
Mitsubishi FusoMC110495
Monroe Shocks & Struts34602, 660161, 76602
NAPA Shocks66602
NEWAY57366602
NavistarAMS660161
OEMMC826268, 5610130Z01, MC110495
UD5611030Z01, 56110Z5011, 5610130Z01, 56101Z5011

MONROE 66602 Fits Vehicles

  • International 500 (1991)
  • Mitsubishi Fuso FH (1988-2004)
  • UD 2300DH (2005-2013)
  • UD 2300LP (2005-2013)
  • UD 2000 (1998-2013)
  • UD 1800 (1995-1998, 2011-2013)
