MONROE 66101 Magnum® Cab Shock Absorber - for Peterbilt 335/348/365//367/379/386/388/White/GMC WIA

$59.49

Limited availability at this price!

In Stock

Get it by Thursday, Feb 19
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 66101 Part Description

Manufacturer

MONROE

Product Description

Magnum Cab Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use vehicles with cab suspensions
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-in. reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient and consistent control (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 66101 Specifications

Product Attributes

Lower Mount Code LS80
Upper Mount Code LS80
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 7.56 IN
Dust Shield Material Metal
Extended Length 9.96 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.3/4" Sleeve OAL
Parts Pack(s) None
Travel Length 2.4 in
Upper Mount Type Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 1.3/4" Sleeve OAL
Compressed Length 192 MM
Extended Length 253 MM
Travel Length 61 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Center of Loop
Lower Mount Type Loop (Eyelet) Bushing and Sleeve
Lower Mount Code LS80
Upper Mount Code LS80
Mounting Hardware Included No
Grade Type Premium
Active or Passive Suspension Passive
Adjustable Compression No
Adjustable Rebound No
Adjustable Ride Height No

Additional Information

MSDS Sheet Number 01170
Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708800050
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598076205
VMRS Code 016008003
UNSPSC 25172011

MONROE 66101 Cross References

BrandPart Number
66101MM, MAE66101
AutomannA83042
BULLDOG HD SHOCKSHD1214-0536
Bulldog HDHD12140536
Dayton Parts44183042
FCSF347275, F347204
FOX COMMERCIAL TRUCK SHOCKS98030005
Flagg Suspension PartsF66101
GABRIEL83042, 83030, 654812
Gold Shock Absorber9151369
HALDEXSA66101
KENWORTHR716005
MERITORM83042
NAPA Shocks66101
OEM8168617, 2016755, R716005, 3939055
PETERBILT2016775, 2016755, R716005, 20-16755, R71-6005
SACHS NORTH AMERICA317780
Sachs317780
VOLVO / WHITE / GMC8168617
Volvo3939055, 8168617
Volvo GM Heavy Truck3939055, 8168617

MONROE 66101 Fits Vehicles

  • Peterbilt 389 (2008-2023)
  • Peterbilt 388 (2008-2015)
  • Peterbilt 386 (2006-2016)
  • Peterbilt 367 (2008-2023)
  • Peterbilt 365 (2008-2021)
  • Peterbilt 348 (2010-2023)
  • Peterbilt 379 (1990-2007)
  • Peterbilt 335 (2005-2010)
  • White/GMC WIA (1988-1995)
