(888) 312-8812 Login SignupMONROE 65484 Magnum Amortisseur
Tap to view 5 more
MSRP: $182.56
$10249
Save $80.07
Limited availability at this price!
In Stock
Get it by Friday, Jul 10
MONROE 65484 Part Description
Manufacturer
Product Description
Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65484 Specifications
Product Attributes
| Compressed Length | 18.12 IN |
| Compressed Length | 460.2 MM |
| Extended Length | 30 in |
| Extended Length | 762 MM |
| Travel Length | 11.88 in |
| Travel Length | 301.8 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Upper Mount Code | LS54 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173843 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65484 Cross References
| Brand | Part Number |
|---|---|
| 65484MM, MAE65484 | |
| Automann | A85976 |
| BULLDOG HD SHOCKS | HD1215-0073 |
| Bulldog HD | HD12150073 |
| Dayton Parts | 44185976 |
| EUCLID | M83121 |
| FCS | F347235, F347236, F347239, F347200, F347346 |
| Ford | 4C4Z18125CA |
| Ford Genuine Parts | 4C4Z18125CA |
| GABRIEL | 85976, 83121 |
| Gold Shock Absorber | 8150372, 9180202 |
| HALDEX | SA65484 |
| HENDRICKSON | 579051, 4790221, 606753, 606653, 60675001, 6066570, 598511, 606705, 573242, 606709, 60670005, 60675003, 60675003L, H60675003, 573249, 57905001 |
| Hendrickson | 60670005L |
| INTERNATIONAL | 3514952C1 |
| International | 3514952C2 |
| International Harvester (IHC) | 3514952C1, 3514952C2, 60675003 |
| Isuzu | 60670005, 8975179661, 8975179660 |
| KENWORTH | 4790224 |
| Kenworth | 60670005 |
| MERITOR | M89414, M85013 |
| MOTORCRAFT | ASH722, ASH1105 |
| NAPA Shocks | 65484 |
| OEM | 60670005L, 4C4Z18125CA, 3514952C2, 57905001, 3514952C1, 60675003L, 14985, 579051, 60675003, 60670005 |
| PRT HD | 171295 |
| VOLVO / WHITE / GMC | 85107238 |
| Volvo | 3972662 |
| Volvo GM Heavy Truck | 85107238 |
| WESTERN STAR | 579051 |
MONROE 65484 Fits Vehicles
- International WorkStar 7600 (2008-2019)
- International 7600 (2003-2007, 2009-2017)
- Kenworth T380 (2022-2024)
- International 7500 (2002-2020)
- International 7400 (2002-2020)
- International 7300 (2002-2020)
- Autocar LLC. DC-64 (2020-2023)
- International MV607 (2019-2024)
- Autocar LLC. Xpert (2012, 2014-2023)
- International HX520 (2018-2026)
- International HX615 (2017-2022)
- International HX515 (2017-2022)
- International HX620 (2017-2026)
- Kenworth T370 (2010-2014)
- Kenworth T270 (2010-2014)
- International LoneStar (2009-2022)
- International 4400LP (2008-2019)
- International 4300LP (2008-2019)
- International 4300 (2008-2019)
- International 4400 (2008-2019)
- Isuzu FTR (1997-2011, 2018-2024)
- Isuzu FVR (1997-2011)
- Ford F-750 (2003-2013, 2015)
- Ford F-650 (2003-2013, 2015)
