(888) 312-8812 Login SignupMERITOR M85013 Suspension Shock Absorber, Standard, 2.13 in. Body Diameter, 1.26 in. Shock Absorber Bore Size
Tap to view 1 more
MSRP: $142.67
$9499
Save $47.68
Limited availability at this price!
In Stock
Get it by Thursday, Aug 27
MERITOR M85013 Part Description
Manufacturer
Product Description
Shock Absorber
Meritor Suspension Shock Absorber
The Meritor Suspension Shock Absorber is worth replacing when the suspension still bounces after the spring has done its part. In daily service, a weak shock can make a truck feel loose over rough pavement, slow to settle after loading, or harsh when the axle rebounds. The 307 mm stroke gives the damper enough working range to control suspension movement through normal road impact and load changes. For suspension service, the Meritor M85013 restores damping at the shock mounting position.
| Body Diameter (in.) | 2.19 in. |
| Body Diameter (mm) | 55.5 mm |
| Bore (in.) | 1.63 in. |
| Bore (mm) | 41 mm |
| Collapsed Length (in.) | 17.75 in. |
| Collapsed Length (mm) | 450.8 mm |
| Dust Shield Diameter (in.) | 2.50 in. |
| Dust Shield Diameter (mm) | 63.5 mm |
| Extended Length (in.) | 29.80 in. |
| Extended Length (mm) | 756.9 mm |
| Family Code | 41FCST |
| Hydraulic Stop | Yes |
| Stroke | 306.1 mm |
| Stroke Inch | 12.05 in. |
| Type | Standard |
| VMRS Code | 016-008-003 |
Meritor Shock Absorber
Meritor shock absorber is designed for exceptional day-in and day-out performance for trucks, trailers, and other types of heavy duty commercial vehicles. This shock provides better ride comfort, operational control, and cargo protection than what the competition has to offer.
Features & Benefits
- Advanced gas cell system reduces oil cavitation from heavy use, maximizing damping efficiency and extending shock life
- Hardened piston rod with polished chrome coating for superior corrosion resistance
- Made of premium materials to ensure reliable performance even under extreme conditions
- Controls internal fluid movement as suspension force enters the shock body
- Responds to axle movement through its mounted shock position
MERITOR M85013 Specifications
Product Attributes
| Body Diameter (in.) | 2.13 in. |
| Body Diameter (mm) | 54 mm |
| Bore (in.) | 1.26 in. |
| Bore (MM) | 32 mm |
| Brand | Meritor |
| Collapsed Length (in.) | 17.83 in. |
| Collapsed Length (mm) | 453 mm |
| Dust Shield Diameter (in.) | 2.56 in. |
| Dust Shield Diameter (mm) | 65 mm |
| Extended Length (in.) | 29.92 in. |
| Extended Length (mm) | 760 mm |
| Family Code | 41FCST |
| Hydraulic Stop | Yes |
| Pallet Quantity | 198 |
| Stroke | 307 mm |
| Stroke Inch | 12.08 in. |
| Type | Standard |
| Weight | 7.45 |
| Body Diameter | 2.13 in. |
| Compressed Length | 17.83 in. |
| Dust Shield Diameter | 2.56 in. |
| Extended Length | 29.92 in. |
| Shock Absorber Bore Size | 1.26 in. |
| Shock Stroke | 307 mm |
| Type | Standard |
MERITOR M85013 Cross References
| Brand | Part Number |
|---|---|
| 85013, 650420, B46-1594, 14QK29403M, 14QK29408M, 14QK366P4, 3099089, 3199947, 3514952C1, 47902024, 4790224, 485303000, 5621000Z11, 57643, B461594, MERM85013, TDAM85013 | |
| AUTOMANN | A85013 |
| BILSTEIN | B46-1594 |
| BLUEBIRD | 1668730, 1722222 |
| BLUEBIRD SCHOOL BUS | 1668730, 1722222 |
| DAYTON PARTS BATCO | M65401, M65420, M65484 |
| FLEETRITE | AMS650401, AMS650420 |
| FORD | 47902-28, F6HZ-18080-FC, F6HZ-18125-D, F6HT-18080-FC |
| Fleetrite | AMS600108, AMS660108 |
| Ford | 4790228, F6HT18080FC, F6HZ18080FC, F6HZ18125D |
| GABRIEL | 85013, 728625, 89414 |
| HALDEX | SA65401, SA65420, SA66710, SA66894 |
| HENDRICKSON | 60670-009, S-2240, 4790228, 60670009 |
| HENDRICKSON TRAILER SUSPENSION SYSTEMS | A-2240, S-2240, 665532 |
| HENDRICKSON TRUCK SUSPENSION SYSTEMS | 47902-28, 60670-009, 654899 |
| HENDRICKSON TURNER | A2240 |
| INTERNATIONAL (NAVISTAR) | AMS650420, AMS |
| International | AMS650420 |
| KONI | 88-1558, 881558 |
| KYB | KG6415 |
| MAECO | 70663 |
| MERITOR | M89414 |
| MONROE | 557001, 65420, 65401, 65484, 66672, 557015 |
| MOTORCRAFT | CAX-894 |
| Monroe Shocks & Struts | 65401, 65420, 65484 |
| Motorcraft | CAX894 |
| PETERBILT | 02-02739, 02-02061, 12887-01, 12887-02, 665657 |
| Paccar Parts | 665632 |
| Peterbilt | 202061, 202739 |
| REYCO | 1288701, 1288702 |
| REYCO SUSPENSION | 12887-01, 12887-02 |
| Reyco Granning | 1288702, 1288701 |
| SAF-HOLLAND | 57643 |
| SPARTAN | MOTORS |
| SPARTAN MOTORS | 0346-SS5 |
| STERLING TRUCK | 47902-28, F6HT-18080-FC, F6HZ-18125-D |
| Sterling | 4790228, F6HT18080FC, F6HZ18125D |
| TRAILMOBILE CANADA CORP. | 43-8-014, 43-6-158 |
| TRUCKMASTER | 665632 |
| Trailmobile | 436158, 438014 |
| VOLVO | 37301-0001, 3916352 |
| Volvo | 373010001 |
MERITOR M85013 Customer Reviews
No reviews yet
Be the first to review this product!
MERITOR M85013 Manufacturer Information
Meritor®, whose roots could be traced back to 1909, is backed by over 100 years of industry experience plus a massive portfolio of products for various industries. In 1998, it made several acquisitions, including Volvo Trucks' heavy vehicle manufacturing operation in Sweden, Euclid Industries, and Lucas Varity's Heavy Vehicle Braking Systems division. Such investments solidify Meritor's position as the leading global supplier of brakes, axles, drivelines, transmissions, suspensions, tire inflations systems, and a whole lot of parts, hardware, and accessories for the automotive, truck, trailer, rail cars, bus and coach, and many other applications. Its "Run with the Bull" global brand identity further strengthens its commitment to provide the industry with durable products, unparalleled service and support, and continuous innovation.
