(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | L4 |
| Upper Mount Code | L4 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Part Description | Shock Absorber |
| Compressed Length | 17.875 IN |
| Dust Shield Material | Metal |
| Extended Length | 28.25 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL |
| Parts Pack(s) | None |
| Travel Length | 10.375 in |
| Upper Mount Type | Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL |
| Compressed Length | 454 MM |
| Extended Length | 717.6 MM |
| Travel Length | 263.5 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Lower Mount Type | Loop (Eyelet) Bushing |
| Lower Mount Code | L4 |
| Upper Mount Code | L4 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173355 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| 65435MM, MAE65435 | |
| Alliance Parts | ABPN32G900024, ABPN32O900024 |
| BULLDOG HD SHOCKS | HD1215-0021 |
| Bulldog HD | HD12150021 |
| Dayton Parts | 44185901 |
| FCS | F347271 |
| FREIGHTLINER | 1012542000 |
| GABRIEL | 85901, 665927 |
| Gold Shock Absorber | 9180198 |
| HALDEX | SA65435 |
| INTERNATIONAL | AMS650435 |
| MACK | 650435MT |
| MERITOR | M85901 |
| MONROE VINTAGE | 70419 |
| Monroe Shocks & Struts | 70419 |
| NAPA Shocks | 65435 |
| NAVISTAR | AMS65435 |
| NEWAY | 57365435 |
| Navistar | AMS650435 |
| OEM | 1012542000 |
| PACCAR PARTS | 665927 |
| POWER10 PARTS | SSA-85901 |
| SACHS NORTH AMERICA | 316309 |
| Sachs | 316309 |
