MONROE 5778 Part Description
Manufacturer
Product Description
OESpectrum Rear Suspension Shock Absorber
Features & Benefits
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 5778 Specifications
Product Attributes
| Compressed Length | 11.5 IN |
| Compressed Length | 292.1 MM |
| Extended Length | 17.875 in |
| Extended Length | 454 MM |
| Travel Length | 6.375 in |
| Travel Length | 161.9 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS47 |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Upper Mount Code | S4 |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01417 |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598019097 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 5778 Cross References
| Brand | Part Number |
|---|---|
| 5778ST, GD9Z17682GCPTM | |
| ACDELCO | 560-600 |
| ACDelco | 560600 |
| AUTOZONE | TS32-30022B, TS32-30082B |
| AutoZone | TS3230022B, TS3230082B |
| Chevrolet | 10363556, 10379372, 15910695, 20939832, 20939833, 22716372, 22716373, 22719455, 22723332, 22731554, 22761744, 22811082, 22811094, 25839736, 25920062, 25920063, 25920064, 25920065, 10379370 |
| Duralast | TS3230022B, TS3230082B |
| FCS | 341615 |
| FCS AUTO PARTS | 341615 |
| GABRIEL | 69590 |
| GMC | 25831693, 25839736, 22761744, 15910695, 21992813, 22723332, 22731554, 15231182, 10379370, 10379371, 21992812 |
| General Motors | 10379370, 10379371, 15231182, 15910695, 21992812, 21992813, 22723332, 22731554, 22761744, 25831693, 25839736 |
| KYB | 349008, 343454, SA1015 |
| KYB AMERICA LLC. | 349008 |
| Monroe Shocks & Struts | 210105 |
| NAPA | SH69589, SH69590 |
| NAPA Proformer | SH69590, SH69589 |
| NAPA Shocks | 5778 |
| OEM | 15910695, 21992812, 22723332, 22761744, 10379370, 25831693, 22731554, 10379371, 25839736, 15231182, 21992813 |
| Pontiac | 10379370, 10379371, 15231182, 15910695, 19180743, 19180744, 21992812, 21992813, 22716368, 22716369, 22723332, 22731554, 25831690, 25831693, 25839736, 25867417, 25867418 |
| SENSEN | 12130306 |
| Saturn | 15910695, 22723332 |
| Top Quality | 785778 |
| UNITY AUTOMOTIVE | 251040, 4-11671-251040-001, 2-251040-001 |
| Ultra Shock | 69590 |
MONROE 5778 Fits Vehicles
- Chevrolet Corsa (2002-2008)
- Saturn Aura (2007-2009)
- Pontiac G6 (2005-2010)
- Chevrolet Malibu (2004-2012)
