Name: MONROE 557011
SKU: 557011
Price: 89.48 USD
Availability: InStock

MONROE part description

Product Description

Magnum RV Shock Absorber

Application Summary

2002-2005 Freightliner XC (Front) (Qualifier: To 22,000 GVW, 23,000 GVW and Over, Replaces OE Part Number(s) B462545M100, with AS90 Beam Suspension, with AS120 Beam Suspension, For additional OE Part Number cross reference information, please refer to the product interchange, Replaces OE Part Number(s) 1616737000, with AS120 Suspension); 1995-2015 Freightliner XB Line (Front) (Qualifier: Replaces OE Part Number(s) 1616737000, with AS120 Suspension)

Features & Benefits

FOR RECREATIONAL VEHICLES -- Designed to handle the demands of recreational vehicles that go on cross country adventures and trips close to home
Robusto bloqueo hidráulico: Evita la extensión excesiva de la suspensión, el tope del pistón y evita daños en el conjunto del retén.
CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to improve performance (when required)
Cojinete recubierto de PTFE: Reduce la fricción durante el funcionamiento entre la barra y la guía de la barra, mejorando la durabilidad
EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the bore provides more efficient and consistent control (most applications)
Bujes con rebordes Tenneco: Bujes con rebordes y bujes adheridos con diseños de manguito que evitan la salida del buje para mejorar la calidad y la durabilidad, en la mayoría de las aplicaciones
STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
Cargado con gas nitrógeno: Para una mejor conducción y manejo, ayuda a mantener el contacto de la llanta con el suelo al reducir la aireación - en la mayoría de las aplicaciones
BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (when required)
Técnica de soldadura en bucle: Soldadura por resistencia con soldadura adicional de 360 ??grados para proporcionar hasta 15,000 libras (6.804 kg)de resistencia a la tracción para una máxima durabilidad (cuando sea necesario)
REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
Tubo de reserva de 2 pulgadas (50,8 mm) o 2-3/8 pulgadas (60,3 mm): El tubo de reserva de 2" (Serie 555xx) o 2-3/8' (Serie 557xx) retiene más fluido o un rendimiento más consistente - cuando sea necesario
IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
Tubo de presión de .05 pulgadas que soporta una presión de 9 KPSI
Fluido para todo clima: Contiene modificadores especiales para reducir la fricción y asegurar una reacción suave de la barra.

Product Attributes

Compressed Length	15.25 IN
Travel Length	8.625 in
Extended Length	23.875 in
Gas Charged	Yes
Dust Shield Included	Yes
Dust Shield Material	Rubber
9783	No
9789	LS39
9791	LS54
9792	Yes
9908	No
Lower Mount Type	Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Part Description	Shock Absorber
Parts Pack(s)	None
Upper Mount Type	Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 41.28MM Sleeve OAL

Additional Information

Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708803000
Harmonized Tariff Code (Schedule B)	8708801600
Harmonized Tariff Code (HTS)	8708801600
MSDS Sheet Number	01164
UPC	00048598557117
VMRS Code	016008003
UNSPSC	25172011

Part Interchanges
