(888) 312-8812 Login SignupMONROE 34671 Gas-Magnum Suspension Shock Absorber
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
MONROE 34671 Part Description
Manufacturer
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
MONROE 34671 Specifications
Product Attributes
| Lower Mount Code | LS26 |
| Upper Mount Code | LS26 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 13.625 IN |
| Dust Shield Material | Metal |
| Extended Length | 21.625 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 8 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL |
| Compressed Length | 346.1 MM |
| Extended Length | 549.3 MM |
| Travel Length | 203.2 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050557 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 34671 Cross References
| Brand | Part Number |
|---|---|
| 34671MM, FT4Z5810176DA | |
| FCS | 342500, 342505 |
| FCS AUTO PARTS | 342500, 342505 |
| Ford | F75Z18124CA, F75Z18124CB, F75Z18124DA, F75Z18124DB, F75Z18124FA, F75Z18124FB, F75Z18124LA, F75Z18124LAA, F75Z18124TA, F75Z18124UA, F75Z18124UB, F75Z18125AC, F75Z18125AD, F75Z18125AE, F75Z18125AF, F75Z18125DB, F75Z18125KB, F75Z18125KC, F75Z18125LB, F75Z18125LC, F75Z18125NB, F75Z18125NC, F75Z18125UB, F75Z18125UC, F85Z18124FA, XL1Z18124AA, XL1Z18125AA |
| GABRIEL | 58717, 61614 |
| KYB | 344267, KG54320, 344377, 565005, 565007, KG54319 |
| NAPA Shocks | 76671 |
| Rancho | RS5118, RS55118 |
| Sensen | 12140148 |
MONROE 34671 Fits Vehicles
- Ford Expedition (1997-2002)
