MONROE 5624 OESpectrum Amortisseur

★★★★★ (0)
Monroe 5624 Suspension Shock Absorber OESpectrum Amortisseur
MONROE
Tap to view 11 more
Monroe 5624 Suspension Shock Absorber OESpectrum Amortisseur

MSRP: $126.58

$72.99

Save $53.59

Limited availability at this price!

In Stock

Get as soon as Tuesday, Nov 24
30-day Return Policy On eligible items Details
Free Ground shipping on orders over $499 details
Orders placed over the weekend will be processed the next business day.

MONROE 5624 Part Description

Manufacturer

MONROE

Product Description

OESpectrum Rear Suspension Shock Absorber

Features & Benefits

  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Twin Technology™ Active Control System delivers exceptional control under most driving conditions while isolating impact-related noise, vibration and harshness
  • DURABLE CONSTRUCTION -- Piston rod and reserve tube deliver added strength and resist deformation under demanding driving conditions
  • EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
  • EXCEPTIONAL HANDLING -- Consistent damping force in compression and rebound delivers better performance and handling in severe driving conditions
  • CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
  • CONTROL AND DURABILITY -- PTFE-banded piston, pressure tube and precision roll-close operation provide consistent sealing and structural strength for better control and long-term durability
  • CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Application-specific valving helps dampen road conditions while isolating impact-related noise, vibration and harshness
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • CONSISTENT PERFORMANCE -- Nitrogen charge minimizes aeration and shock fade to keep damping consistent, reduce bounce and maintain tiretoroad contact for better handling in demanding conditions
  • BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
  • BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee

MONROE 5624 Specifications

Product Attributes

Compressed Length15.5 IN
Compressed Length393.7 MM
Extended Length24.5 in
Extended Length622.3 MM
Travel Length9 in
Travel Length228.6 MM
Lower Mount TypeSpecial Mount
Lower Mount TypeLoop (Eyelet) Bushing and Sleeve
Lower Mount CodeSPEC
Upper Mount TypeStem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Upper Mount CodeS4
Shock Absorber Rod End Measuring PointBase of Stem
Gas ChargedYes
Mounting Hardware IncludedYes
Parts Pack(s)P01136
Body ColorBlack
Cylinder ColorBlack
ColorBlack
Cylinder FinishPainted
Dust Shield IncludedNo
Includes Bump StopNo
Internal Rebound BumperNo
Hydraulic LockoutNo
Grade TypePremium
Active or Passive SuspensionPassive
Adjustable CompressionNo
Adjustable ReboundNo
Adjustable Ride HeightNo
Part DescriptionShock Absorber

Additional Information

MSDS Sheet Number01168
Country of Origin (Primary)CN
Canadian Harmonizing Tariff Code8708803000
Harmonized Tariff Code (Schedule B)8708800050
Harmonized Tariff Code (HTS)8708801600
UPC00048598054715
VMRS Code016008003
UNSPSC25172011

MONROE 5624 Cross References

BrandPart Number
5624ST, GB5Z12A650HANP
AUTOZONETS34-35032B, TS33-33202B
AutoZoneTS3333202B, TS3435032B
Autopart International2701412063
DuralastTS3333202B, TS3435032B
FCS341624, 346054, 341388
FCS AUTO PARTS341624, 346054
GABRIELG51783, 70055
KYB343442, 348001, 348069, 343823
KYB AMERICA LLC.348001, 348069
MasterPro Shocks and StrutsTY124
Monroe Shocks & Struts210065
NAPA Shocks5624, 94382, NS5624
OEM4853080350, 4853052M30, 4853080554, 4853052J60, 4853080438, 4853052G20, 4853080324, 4853080347, 4853080340, 4853080636, 4853052J30, 4853052L00, 4853080351, 4853080639, 4853052G40, 485300D820, 4853052J20
OSCS343442
PM AutoPM6000950
PRT170714
SENSEN32120276
Scion4853080438
TRQSBA60729
Top Quality785624
Toyota485100D770, 4851052C30, 4851052C50, 4851052G10, 4851052G40, 4851052G41, 4851052J20, 4851052J30, 4851052J60, 4851052L10, 4851052L11, 4851080196, 4851080294, 4851080516, 485200D220, 4852052140, 4852052160, 4852052510, 4852052540, 4852052541, 4852052620, 4852052630, 4852052660, 4852052810, 4852052811, 4852059195, 4852059365, 4852080246, 485300D820, 485300DA10, 485300DA40, 4853052G20, 4853052G40, 4853052J20, 4853052J30, 4853052J60, 4853052L00, 4853052M30, 4853080324, 4853080340, 4853080347, 4853080350, 4853080351, 4853080554, 4853080636, 4853080639, 4853080438
UNITY AUTOMOTIVE4-11805-254130-001, 4-13071-254130-001, 2-254130-001, 254130
Ultra Spring SeatG51783
Unity254130

MONROE 5624 Fits Vehicles

  • Scion xD (2008-2010)
  • Toyota Prius C (2012-2019)
  • Toyota Yaris (2006-2014)
