(888) 312-8812 Login SignupCENTRIC 125.34063 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 2 more
$169.63
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 125.34063 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.34063 Specifications
Product Attributes
| Notes [cntrc] | Vented Hat |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 12.370 |
| Weight [cntrc] Lbs | 27.210 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 5 |
| Disc Mounting [cntrc] | Floating |
| Discard Thickness | 30.400 MM |
| Discard Thickness | 1.197 IN |
| Nominal Thickness | 1.260 IN |
| Nominal Thickness | 32.000 MM |
| Hat Finish | Painted |
| Overall Height | 77.200 MM |
| Overall Height | 3.039 IN |
| Outside Diameter | 345.000 MM |
| Outside Diameter | 13.583 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 79.000 MM |
| Center Hole Diameter | 3.110 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.579 IN |
| Stud/Lug Hole Diameter | 14.700 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890729648 |
CENTRIC 125.34063 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD180113, 45400, 25740, 90031057D, 34112229528 |
CENTRIC 125.34063 Fits Vehicles
- BMW M5 (2000-2003)
