(888) 312-8812 Login SignupMONROE 911196 OESpectrum Amortisseur
Tap to view 11 more
MSRP: $118.53
$6599
Save $52.54
Limited availability at this price!
In Stock
Get it by Friday, Jul 24
MONROE 911196 Part Description
Manufacturer
Features & Benefits
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 911196 Specifications
Product Attributes
| Compressed Length | 18.25 IN |
| Compressed Length | 463.5 MM |
| Extended Length | 31 in |
| Extended Length | 787.4 MM |
| Travel Length | 12.75 in |
| Travel Length | 323.8 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS26 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Upper Mount Code | L1 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01170 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598841209 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 911196 Cross References
| Brand | Part Number |
|---|---|
| 911196MM, 829352491775 | |
| ACDelco | 52563 |
| Duralast | TS3331452B |
| FCS | 342509, 342511, 342510 |
| FCS AUTO PARTS | 342509, 342511 |
| Ford | 1C3Z18124EA, 1C3Z18125LA, 2C3Z18125AA, 2C3Z18125BA, 3C3Z18124AA, 3C3Z18124BA, 3C3Z18124CA, 3C3Z18124DA, 3C3Z18124EA, 3C3Z18124FA, 3C3Z18124GA, 3C3Z18124HA, 3C3Z18124JA, 3C3Z18124KA, 3C3Z18124LA, 3C3Z18124MA, 3C3Z18124NA, 3C3Z18124NB, 3C3Z18124PA, 3C3Z18125CA, 3C3Z18125FA, 3C3Z18125GA, 3C3Z18125HA, 3C3Z18125JA, 3C3Z18125JB, 3C3Z18125JC, 3C3Z18125JD, 3C3Z18125JE, 3C3Z18125KA, 3C3Z18125KB, 3C3Z18125KC, 3C3Z18125KD, 3C3Z18125KE, 3C3Z18125LA, 3C3Z18125LB, 3C3Z18125LC, 3C3Z18125LD, 3C3Z18125LE, 3C3Z18125MA, 3C3Z18125MB, 3C3Z18125MC, 3C3Z18125MD, 3C3Z18125ME, F81Z18124AA, F81Z18124AB, F81Z18124AC, F81Z18124AE, F81Z18124AF, F81Z18124AG, F81Z18124AH, F81Z18124AJ, F81Z18124AK, F81Z18124AL, F81Z18124AM, F81Z18124AP, F81Z18124BA, F81Z18124BB, F81Z18124BC, F81Z18124BD, F81Z18124BE, F81Z18124BF, F81Z18124BG, F81Z18124BH, F81Z18124BJ, F81Z18124BK, F81Z18125CA, F81Z18125CB, F81Z18125CC, F81Z18125CD, F81Z18125CE, F81Z18125CF, F81Z18125CG, F81Z18125CH, F81Z18125CJ, F81Z18125CK, F81Z18125CL, F81Z18125CM, F81Z18125CN, F81Z18125CP, F81Z18125CQ, F81Z18125CR, F81Z18125CS, F81Z18125CT, F81Z18125CV, F81Z18125CW, F81Z18125CX, F81Z18125CZ, F81Z18125DG, F81Z18125DH |
| GABRIEL | 77810, G63810, G63461 |
| KYB | 565091, KG54333, 344413, 565100, KG54332, KG5044, 344419, 344382 |
| KYB AMERICA LLC. | KG5044, KG54333 |
| MasterPro Shocks and Struts | FD110 |
| Monroe Shocks & Struts | 32359, 34687, 210440 |
| NAPA Shocks | 911196, NS911196 |
| NAVISTAR | AMS911196 |
| Rancho | RS55273 |
| SENSEN | 12140211 |
| UNITY AUTOMOTIVE | 253150, 2-253150-001 |
MONROE 911196 Fits Vehicles
- Ford F-350 Super Duty (1999-2004)
- Ford F-250 Super Duty (1999-2004)
