MONROE 66104 Part Description
Manufacturer
Product Description
Magnum Cab Cab Suspension Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use vehicles with cab suspensions
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-in. reserve tube holds more fluid to improve performance (when required)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient and consistent control (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 66104 Specifications
Product Attributes
| Compressed Length | 7.25 IN |
| Compressed Length | 184.1 MM |
| Extended Length | 9.375 in |
| Extended Length | 238.1 MM |
| Travel Length | 2.125 in |
| Travel Length | 54 MM |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 7/16" Sleeve ID X 1.3/8" Sleeve OAL |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS14 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 7/16" Sleeve ID X 1.3/8" Sleeve OAL |
| Upper Mount Code | LS14 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Grade Type | Premium |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01168 |
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598076489 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 66104 Cross References
| Brand | Part Number |
|---|---|
| 66104MM, MAE66104 | |
| Alliance Parts | ABPN32G900018, ABPN32O900018 |
| Automann | A83021, A83049 |
| BULLDOG HD SHOCKS | HD1213-0651 |
| Bulldog HD | HD12130651 |
| Dayton Parts | 44183021 |
| FCS | F347222, F347252 |
| FREIGHTLINER | 12020054 |
| Freightliner | 12010054 |
| GABRIEL | 83021, 654841, 83020 |
| Gold Shock Absorber | 8160523 |
| HALDEX | SA66104 |
| Kenworth | 12020054 |
| LINK CAB | 12011046 |
| Link | 12011046 |
| MARMON | 12020054 |
| MERITOR | M83021 |
| Meritor | M83049 |
| NAPA Shocks | 66104 |
| OEM | 12020054 |
| PETERBILT | 12020054 |
| POWER10 PARTS | SSA-83021 |
| Peterbilt | 12010054 |
| SACHS NORTH AMERICA | 316825 |
| Sachs | 316825 |
MONROE 66104 Fits Vehicles
- Peterbilt 359 (1981-1988)
- Freightliner FLB (1994-1999, 2002)
- Peterbilt 377 (1987-2001)
- Peterbilt 376 (1988-1992, 1994-1996, 1999)
- Peterbilt 375 (1987-1996)
- Kenworth T400 (1982, 1984, 1989-1999)
- Peterbilt 379 (1986-2007)
- Peterbilt 378 (1990-2007)
- Peterbilt 357 (1986-2008)
- Kenworth W900 (1982-2020)
- Kenworth T800 (1987-2015)
- Kenworth T600A (1986-2008)
- Freightliner FL70 (1991-2005)
- Freightliner FL60 (1991-2004)
- International 9800 SBA (1996-1999)
- International 9700 (1989-1996)
- International 9600 (1989-1996)
- Chevrolet C70 Kodiak (1990-1996)
