*Representative image - actual part not displayed
Centric 130.61016 - Centric Premium Brake Master Cylinder
$8549
MSRP: $96.59
Save: $11.10
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Product Attributes
| Push Rod: Length / Depth [cntrc] In | 0 |
| Boss, Nipple Or Port: Rear: #a [cntrc] | 1/2"-20 inv |
| Weight [cntrc] Kgs | 2.77 |
| Secondary Outlet Flare Type [cntrc] | Inverted |
| Publication Bore [cntrc] | 1" |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | 9/16"-18 inv |
| Weight [cntrc] Lbs | 6.1 |
| Primary Outlet Flare Type [cntrc] | Inverted |
| Product Grade [cntrc] | Premium |
| Reservoir Material | Cast Iron |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 25.400 MM |
| Master Cylinder Bore Diameter | 1.000 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 0.500 IN |
| Secondary Outlet Thread Diameter | 0.5625 IN |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| 9275 | 18 IN |
| 9276 | 20 IN |
| Bore Type | Straight |
| Bore Size | 25.400 MM |
| Bore Size | 1.000 IN |
| Secondary Outlet Thread Size | 9/16"-18 |
| Primary Outlet Thread Size | 1/2"-20 |
| Primary Outlet Flare Type | Inverted |
| Secondary Outlet Flare Type | Inverted |
| Primary Bore Diameter | 25.400 MM |
| Primary Bore Diameter | 1.000 IN |
| Reservoir Style | Integral |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890006503 |
Part Interchanges
CENTRIC 130.61016 Cross Reference
We have 5 alternatives for the 130.61016 by CENTRIC:
Fits Vehicles
- Mercury Villager (1967)
- Mercury Voyager (1967)
- Mercury Montego (1968-1971)
- Mercury Cyclone (1966-1971)
- Mercury Cougar (1971-1972)
- Mercury Comet (1966-1969, 1971-1973)
- Mercury Caliente (1967)
- Ford Torino (1968-1971)
- Ford Ranchero (1967-1971)
- Ford Mustang (1971-1973)
- Ford Maverick (1970-1973)
- Ford Falcon (1967-1970)
- Ford Fairlane (1967-1970)
- Ford Country Squire (1969-1970)
