(888) 312-8812 Login SignupCENTRIC 125.61061 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 4 more
$7049
Limited availability at this price!
1 Day Lead Time
Get it by Tuesday, Jun 16
CENTRIC 125.61061 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.61061 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 5.450 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Lbs | 12.000 |
| Disc Mounting [cntrc] | Floating |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20.000 MM |
| Nominal Thickness | 22.000 MM |
| Nominal Thickness | 0.866 IN |
| Hat Finish | Painted |
| Overall Height | 43.400 MM |
| Overall Height | 1.709 IN |
| Outside Diameter | 257.900 MM |
| Outside Diameter | 10.154 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 63.600 MM |
| Center Hole Diameter | 2.504 IN |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 13.800 MM |
| Stud/Lug Hole Diameter | 0.543 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 00805890131892 |
CENTRIC 125.61061 Cross References
| Brand | Part Number |
|---|---|
| N/A | FR08073, BD125703, 422172, 522172, E125-66-066, E130-66-066, BR5407902, 9 66913, 54079, 54079G, M2S651125BA, 3049893, 1M5Z1V125AA, 3555344, 3573537, 4077455, 3L4Z1125AA, 3S4Z1125AA, YS4Z1125BA, YS4Z1125DA, YS4Z1125DB, 2S651125BA, 1373771, 1388256, 1464916, 1465322, 1465622, 1522230, 2S611125AA, 7S611125BA, 98A61125AE, 98AB1125BD, 98AB1125BE, 98AB1125D1E, 98AB1125DC, 98AB1125EA, 98AB1125EB, 98AG1125E1B, 98AG1125EA, 98AG1125EB, 98AX1125BE, 98AX1125BF, 98AX1125E1B, XS6W1125B1B, YS6W1125BB, 98AB-11-25BE, 98AB-11-25D1E, DD59-33-25XA, DD633325XA, DD593325XA, DD633325X, DD593325X, DD323325X, 1499045, 1323620, 1320585, 1148202, 145273, 4886913, 86913, BFR126310, AR8161, E12566066, 54079HC, 1.1752.2.4, 125.61061, 54079DSR, YH145273, 1407-25676, 54079DSL, A5881, I1242, 27149, 09780610, 66913P, DDF1072, 19905, 8934061, 90054045, 18A967A, 250.1343.00, 2298 |
| RAYBESTOS | 66913, 66913FZN, 66913R, 66913R2 |
| Raybestos Brakes | 66913, 66913FZN, 66913R |
| WAGNER | BD125703, BD126023E |
CENTRIC 125.61061 Fits Vehicles
- Ford Fiesta (2005-2009)
- Ford EcoSport (2004-2012)
- Ford Focus (2000-2004)
