(888) 312-8812 Login SignupCENTRIC 123.48002 C-Tek Standard Brake Drum
Tap to view 4 more
$4299
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Jul 9
CENTRIC 123.48002 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.48002 Specifications
Product Attributes
| Weight [cntrc] Kgs | 3.864 |
| Weight [cntrc] Lbs | 8.500 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 60.000 |
| Hub Hole / Register [cntrc] In | 2.362 |
| Height [cntrc] Mm | 74.000 |
| Height [cntrc] In | 2.913 |
| Friction Surface Width [cntrc] Mm | 36.000 |
| Friction Surface Width [cntrc] In | 1.417 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 182.000 MM |
| Maximum Brake Diameter (Discard) | 7.165 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 221.800 MM |
| Outside Diameter | 8.732 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.000 MM |
| Mounting Hole Diameter | 0.472 IN |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890052081 |
CENTRIC 123.48002 Cross References
| Brand | Part Number |
|---|---|
| 122.48002, F1EZ15K866J | |
| N/A | BD61977, 0802492, 0832492, 35003, BD35003, 63 78 020, 6378020, 4351162B00, 35003G, 116503, 9610, 100859, 96062139, 140591, PDR0591, 240480, 6401668, 1025, JBD192, JBD192E, D9442, 87474, YH140591, 21096, X30754, 9474, 9474DGS, 9474R, 78810007, 8810007, 177399, 36550002 |
| PRONTO | BD35003 |
| RAYBESTOS | 9474, 9474R |
| WAGNER | BD61977 |
CENTRIC 123.48002 Fits Vehicles
- Geo Metro (1989-1997)
- Chevrolet Metro (1998-2000)
- Suzuki Swift (1989-1990, 1995-2001)
