(888) 312-8812 Login SignupCENTRIC 120.65058 Centric Premium Brake Rotor
Tap to view 4 more
$82.20
MSRP Pricing shown.
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.65058 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.65058 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.950 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 17.500 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 27.700 MM |
| Discard Thickness | 1.091 IN |
| Nominal Thickness | 1.181 IN |
| Nominal Thickness | 30.000 MM |
| Hat Finish | Painted |
| Overall Height | 1.858 IN |
| Overall Height | 47.200 MM |
| Outside Diameter | 308.000 MM |
| Outside Diameter | 12.126 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 92.600 MM |
| Center Hole Diameter | 3.646 IN |
| Mounting Bolt Hole Circle Diameter | 135.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.315 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.200 MM |
| Stud/Lug Hole Diameter | 0.598 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890043577 |
CENTRIC 120.65058 Cross References
| Brand | Part Number |
|---|---|
| 66647, BD125513 | |
| N/A | BD125513, E125-70-063, 6492300, 54044, 54044G, 107174, F75A1125AC, F75W2B663BA, F75Z1104BB, F75Z1125BC, F85Z1125BA, YL7Z1V125AA, XL1Z1102AA, XL1Z1125AA, XL1Z1125BA, 145142, 86630, 86647, 4886647, AR8558, E12570063, 54044HC, 54044DSR, 210792, 210792C, YH145142, 54044DSL, 27011, 19757, 8942058, 90054148, 90054176 |
| NEOTEK | 107174GF |
| Neotek Premium Drums and Rotors | 107174GF |
| PRONTO | BR5408002 |
| RAYBESTOS | 66647, 66647FZN, 66647R |
| Raybestos Brakes | 66647, 66647FZN, 66647R |
| WAGNER | BD125727E, BD125727 |
CENTRIC 120.65058 Fits Vehicles
- Lincoln Navigator (1998-2000)
- Ford Expedition (1997-2000)
