RAYBESTOS 66647FZN Raybestos Element3 Coated Brake Rotor

★★★★★ (0)
Raybestos 66647FZN Disc Brake Rotor Raybestos Element3 Coated Brake Rotor
RAYBESTOS

MSRP: $86.42

$79.49

Save $6.93

Limited availability at this price!

In Stock

Get it by Tuesday, Aug 18
No Hassle Return Policy Details
Free Ground shipping on orders over $499 details

RAYBESTOS 66647FZN Part Description

Manufacturer

RAYBESTOS

Product Description

Raybestos Element3 Coated Brake Rotor

Application Summary

2000-1997 Ford Expedition Front, 2000-1998 Lincoln Navigator Front

Features & Benefits

  • Grey Fusion 4.0® Coating
  • Grey Fusion 4.0(R) Coating
  • Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
  • Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
  • RPT® Rust Prevention Technology
  • RPT(R) Rust Prevention Technology
  • RPT® Rust Prevention Technology for long lasting rust prevention.
  • RPT(R) Rust Prevention Technology for long lasting rust prevention.
  • Cooling Vanes
  • Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
  • OE Matched
  • OE Matched precision and performance.
  • Non-Directional Finish
  • A non-directional ground finish provides a product that is ready to install right out of the box.

RAYBESTOS 66647FZN Specifications

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 3.64 IN
Center Hole Diameter 92.45 MM
Conventional Or Drum-In-Hat Type Rotor Conventional
Directional or Non-Directional Brake Surface Non-Directional
Discard Thickness 1.091 IN
Discard Thickness 27.7 MM
Harmonize Code 8708.30.5030
Material Cast Iron
Mounting Bolt Hole Circle Diameter 5.315 IN
Mounting Bolt Hole Circle Diameter 135 MM
Mounting Bolt Hole Diameter 0.588 IN
Mounting Bolt Hole Diameter 14.95 MM
Mounting Bolt Hole Quantity 5
Nominal Thickness 1.185 IN
Nominal Thickness 30.1 MM
Outside Diameter 12.12 IN
Outside Diameter 307.85 MM
Overall Height 1.86 IN
Overall Height 47.25 MM
Salability Restrictions No
Solid Or Vented Type Rotor Vented
Stud/Lug Hole Quantity 5
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
Canadian Harmonizing Tariff Code 8708309990
Harmonized Tariff Code (HTS) 8708305030
UPC 00887213228090

RAYBESTOS 66647FZN Cross References

BrandPart Number
ADVANCE AUTO PARTS145142, YH145142, YH145142C, YH145142P
AUTOPART INTERNATIONAL25647
AUTOSPECIALTYAR8558, AR8558E
AUTOXTRA8066647
AUTOZONE54044, 54044B, 54044DG, 54044DL, DL54044
BENDIX145142
BOSCH16010166, RBR54044
BRAKE HEADQUARTERSBR54679
BRAKEBEST16010166, 66647, 66647FZN, 66647R, 66647RGS
BREMBO09.7653.10, 27011
Bridgestone7002443
CALIFORNIA DRUM & ROTOR125513
CENTRIC120.65058, 121.65058, 125.65058, 126.65058CSL, 126.65058CSR, 126.65058SL, 126.65058SR, 127.65058L, 127.65058R, 128.65058CL, 128.65058CR, 128.65058L, 128.65058R, 227.65058L, 227.65058R, 320.65058, 320.65058F, 321.65058
Casting Numbers325217, 5193
Centric Parts120.65058, 121.65058, 125.65058, 126.65058CSL, 126.65058CSR, 126.65058SL, 126.65058SR, 127.65058L, 127.65058R, 128.65058CL, 128.65058CR, 128.65058L, 128.65058R, 227.65058L, 227.65058R, 320.65058, 320.65058F, 321.65058
DELPHIRB58, RB583
DURA CORPBR54044
Dura CorpBR54080
DuraGoBR54044, BR54080
EUROROTOR54210
FORDF75Z1125BC, XL1Z1102AA, XL1Z1125AA
FORMULA BLUE HYDRAULIC BRAKE PARTSE12570063
GREN649202
GUARDIAN52-125513
MIDASBR2047
MIGHTY DISTRIBUTING SYSTEM54044
MOTORCRAFTBRR63
MotorcraftNBRR84
NEWTEK AUTOMOTIVE54044
Newtek Automotive USA54044
PARTS MASTERP125513
POWERSTOPAR8558EVC
PROMAX14-54044
QUALIS54044
QUALITY BRAND54044, Q4128
STANDARD ROTORS AND DRUMS54044
THE UNIVERSAL GROUP102564
TopNotchTN66647GEO
UAP54044
Universal102564
VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURINGX51184
WAGNER BRAKEBD125513
WINHERE442410, YH2410
WORLDPAC1407-25647
Wagner BrakeBD125727E

RAYBESTOS 66647FZN Fits Vehicles

  • Lincoln Navigator (1998-2002)
  • Ford Expedition (1997-2000)
