Centric 120.63059 - Centric Premium Brake Rotor
$6799
MSRP: $94.51
Save: $26.52
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 9.380 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 20.650 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 26.500 MM |
| Discard Thickness | 1.043 IN |
| Nominal Thickness | 1.106 IN |
| Nominal Thickness | 28.100 MM |
| Hat Finish | Coated |
| Overall Height | 54.700 MM |
| Overall Height | 2.154 IN |
| Outside Diameter | 320.000 MM |
| Outside Diameter | 12.598 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 72.500 MM |
| Center Hole Diameter | 2.854 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.657 IN |
| Stud/Lug Hole Diameter | 16.700 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890210450 |
Part Interchanges
- Raybestos Brakes 780255FZN
- Raybestos Brakes 780255R
- Raybestos Brakes 780255
- Neotek Premium Drums and Rotors 107079GF
- BD126263
- BD126263E
- E125-68-064
- BR5302202
- 43086
- 43086G
- 4779196AA
- 4779196AB
- 4779196AD
- 4779196AE
- 4779196AF
- 4779196AG
- 145650
- 53022
- 880255
- E12568064
- 43086HC
- 120.63059
- 43086GT
- 0204262324
- 02042K2036
- 43086DSR
- 1407-26856
- YH145650
- 43086DSL
- 27352
- 780255P
- 2053022
- 19367
- 90039015
CENTRIC 120.63059 Cross Reference
We have 6 alternatives for the 120.63059 by CENTRIC:
Fits Vehicles
- Dodge Magnum (2005-2008)
- Dodge Charger (2006-2022)
- Dodge Challenger (2009-2022)
- Chrysler 300 (2005-2022)
