(888) 312-8812 Login SignupCENTRIC 120.51007 Centric Premium Brake Rotor
Tap to view 4 more
MSRP: $53.89
$4249
Save $11.40
Limited availability at this price!
In Stock
Get it by Thursday, Feb 19
CENTRIC 120.51007 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.51007 Specifications
Product Attributes
| Misc Holes [cntrc] | 3 |
| Weight [cntrc] Lbs | 9.500 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 4.320 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 6.654 |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 169.000 |
| Discard Thickness | 8.400 MM |
| Discard Thickness | 0.331 IN |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10.000 MM |
| Hat Finish | Painted |
| Overall Height | 61.000 MM |
| Overall Height | 2.402 IN |
| Outside Diameter | 262.000 MM |
| Outside Diameter | 10.315 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 168.000 MM |
| Nominal Drum Diameter | 6.614 IN |
| Bearings Included | No |
| Center Hole Diameter | 76.100 MM |
| Center Hole Diameter | 2.996 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 12.500 MM |
| Stud/Lug Hole Diameter | 0.492 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890035275 |
CENTRIC 120.51007 Cross References
| Brand | Part Number |
|---|---|
| 980054, BD126166 | |
| ADVICS | R6R302U |
| ATE BRAKE PRODUCTS | 410317 |
| N/A | 0832901, BD126166, 6482100, YH145532, 31333, 25905, 31333G, 5841138310, 584113C000, 5841138300, 145532, 86616, DDF1448, 2031333, DF4286, JBR777, 60003011 |
| NEOTEK | 106920GF |
| Neotek Premium Drums and Rotors | 106920GF |
| PRONTO | BR3133302 |
| RAYBESTOS | 980054, 980054FZN, 980054R |
| Raybestos Brakes | 980054FZN, 980054R, 980054 |
| WAGNER | BD126166, BD126166E |
CENTRIC 120.51007 Fits Vehicles
- Kia Magentis (2001-2005)
- Hyundai Sonata (1999-2002, 2004-2005)
- Kia Optima (2001-2006)
