(888) 312-8812 Login SignupOE form, fit & function wheel hub unit.
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Wheel Pilot Diameter | 2.362 IN |
| Brake Pilot Diameter | 2.441 IN |
| Wheel Stud Quantity | 5 |
| Flange Shape | Modified Rectangular |
| Drive Type | Non-driven |
| Bearing Type | Ball |
| Flange Offset | 2.933 IN |
| Flange Diameter | 152 MM |
| Bolt Circle Diameter | 4.500 IN |
| Bearing Generation | Gen 3 |
| Knuckle Bolt Circle Diameter (Inches) | 3.898 |
| Knuckle Bolt Circle Diameter (Millimeters) | 99.0 |
| Knuckle Bolt Hole Size | 10.5 MM |
| Knuckle Pilot Hole Diameter | 74 MM |
| Wheel Stud Size | M12X1.5 MM |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8482105016 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810607239 |
| Brand | Part Number |
|---|---|
| Power Train | PT512207 |
| Beck/Arnley | 0516089 |
| Mevotech | H512207 |
| Lexus | 4245006020, 4245006021, 4245048010, 4245048011 |
| GMB | 7700255 |
| Raybestos Brakes | 712207 |
| Drive Tech America | NT512207 |
| DuraGo | 29512207 |
| GSP | 693207 |
| Alltech Automotive | 512207 |
| Toyota | 4245006020, 4245006030, 4245048011, 4245006021, 4245048010 |
| SKF | BR930266 |
| Timken | HA592450 |
| MOOG Chassis Products | 512207 |
| Centric Parts | 407.44001, 407.44001E |
| Parts Master | PM512207 |
| Schaeffler | 102097, RW8207 |
| DT Components | 512207 |
| Autopart International | 141144715 |
| Fenco | WH512207 |
| Parts Plus | P512207 |
| WJB | WA512207 |
