(888) 312-8812 Login SignupGABRIEL 77947 Premium Monotube Shock Absorber
Tap to view 3 more
$7749
Limited availability at this price!
In Stock
Get it by Friday, Jul 3
GABRIEL 77947 Part Description
Manufacturer
Product Description
Premium Monotube Shock Absorber
Features & Benefits
- MaxComfort - Larger bore size inside the pressure tube enables the shocks to react quicker and creates a smoother & more comfortable ride
- MaxEndurance - Single-tube design and multi-stage sealing minimizes chamber temperature & debris for longer-lasting performance
- MaxSafety - Sensitivity & quick response time keep tires in contact with the road to maximize braking effectiveness
- Features a rod guide bearing system for smooth and effortless movements
- D.O.M. (Drawn-Over-Mandrel) tubing reduces internal wear for longer product life
- For sport & off-roading and light/occasional towing & hauling
- Chromed piston rod provides more consistent wear surface for proper seal lubrication over longer life
GABRIEL 77947 Specifications
Product Attributes
| Boot Included | Yes |
| Compression (lb) | n/a |
| Features/Benefits 1 | Larger 46 mm bore size allows the shock to react quicker to bumps and other road imperfections, creating the smoothest ride possible |
| Lower Mount Code | ES34 |
| Mounting Codes 2024.pdf | https://gabriel.com/sites/default/files/Mounting_Codes_2025.pdf |
| Accessory Kit # | 142731 |
| Collapsed Length (in) | 10.88 |
| Extended Length (in) | 15.63 |
| Features/Benefits 4 | Sensitivity and quick response time keep tires in contact with the road to maximize braking effectiveness, keeping you in control at all times |
| Upper Mount Code | S38 |
| Weight (lbs) | 5.20 |
| Core Color | Y |
| Dust Tube Material | n/a |
| Features/Benefits 3 | High-pressure nitrogen gas and floating piston technology allow the shock to immediately react to steering wheel movements, providing the ultimate in handling and performance |
| Recoil Cutoff | n/a |
| Stroke (in) | 4.75 |
| Bore | n/a |
| Dust Tube | n/a |
| Features/Benefits 2 | Single-tube design and multi-stage sealing minimize chamber temperature and debris entry for longer-lasting performance |
| Package Contents | 1 Shock, 2 Bushings, 2 Washer, 1 Nut |
| Rebound (lb) | n/a |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Country of Origin (Primary) | MX |
| MSDS Sheet Number | ARP002 / RC001 |
| UPC | 00043645721930 |
| VMRS Code | 016008031 |
| UNSPSC | 25172011 |
GABRIEL 77947 Cross References
GABRIEL 77947 Fits Vehicles
- Dodge Ram 1500 (2002-2005)
