(888) 312-8812 Login SignupFLEETGUARD HF7535 Transmission
$16199
3 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
FLEETGUARD HF7535 Part Description
Manufacturer
| Attributes | |
|---|---|
| Largest Outside Diameter | 94 mm (3.701 in) |
| Seam Outside Diameter | 98 mm (3.858 in) |
| Gasket Outside Diameter | 71.5 mm (2.815 in) |
| GASKET INSIDE DIAMETER | 62 mm (2.441 in) |
| Thread Size | M23 X 1.5-6H INT |
| Standpipe | NO |
| ADBV | null |
| BPV Setting | 200 kPa (29.01 PSI) |
| TWA MICRON @ BETA=20 | 4 micron (4 micron) |
| TWA MICRON @ BETA=200 | 8 micron (8 micron) |
| TWA MICRON @ BETA=75 | 6 micron (6 micron) |
FLEETGUARD HF7535 Specifications
Product Attributes
| Gasket Inside Diameter | 2.4606250000000003 IN |
| Gasket Outside Diameter | 2.81496215 IN |
| Media Type | Microglass IN |
| Overall Height | 4.29133 in |
| Particle Size at Beta 200 | 6.0 IN |
| Particle Size at Beta 75 | 4.0 IN |
| Pressure Valve | Yes IN |
FLEETGUARD HF7535 Cross References
FLEETGUARD HF7535 Customer Reviews
No reviews yet
Be the first to review this product!
FLEETGUARD HF7535 Manufacturer Information
Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries. Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.
FLEETGUARD HF7535 Questions & Answers
No questions yet
Be the first to ask a question about this product!
