FLEETGUARD part description

Product Description

Lube, By-Pass Spin-On

Product Attributes

Height 10.39 in. (263.91 mm)
Gasket Inside Diameter 3.56 in. (90.42 mm)
Gasket Outside Diameter 3.94 in. (100.08 mm)
Notes By-Pass Spin-On
Outside Diameter (Largest) 4.24 in. (107.7 mm)
Seam Outside Diameter 4.24 in. (107.7 mm)
Standpipe NO
Thread Size 1 3/8-16 UN-2B
Largest Od 4.239 in
Overall Height 263.91 mm

Additional Information

Warranty Distance 100000
Warranty Distance UOM DH
Warranty Time 1
Warranty Time UOM YR
UPC 00638217114922

Part Interchanges

Since 1987, Fleetguard® has been one of the world's leaders in filtration solutions for both on- and off-highway applications. Whether it's air, fuel, oil, or hydraulic filtration, Fleetguard filters provide superior protection against contaminants for engines and sensitive equipment in the agriculture, construction, commercial vehicle, marine, mining, and power generation industries.  Each filter is fitted with high-quality filter media for longer service life as well as a more compact design to accommodate shrinking engine compartments found in modern vehicles. All products also undergo extensive performance tests and strict quality control procedures to ensure durability and consistent performance, even in the most demanding operating conditions.

FLEETGUARD LF3654 Cross Reference

We have 4 alternatives for the LF3654 by FLEETGUARD:
