(888) 312-8812 Login SignupACCURIDE RX984K 6-SPOKE 20"
*Representative image - actual part not displayed
Out of Stock
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
ACCURIDE RX984K Part Description
Manufacturer
The Gunite brand product line includes 100% made in the USA brake drums, disc wheel hubs, spoke wheels and rotors, as well as slack adjusters, for the heavy- and medium-duty trucking, off-highway and bus markets and their related aftermarkets. The Gunite product search includes numerical, interchange/cross-reference, dimensional, application, and conversion features to make it easy to find the exact Gunite wheel end product you need.
| Gunite Part Number: | RX984K | |
| Aftermarket Status: | Obsolete | |
| Captive Part Number To: | ||
| O.E. Service Replacement: | RX248K | |
| Limitations: | Replacement is machined to accept a Tone (Exciter) Ring for Anti-Lock brakes. | |
| Aftermarket Replacement: | RX248K | |
| Limitations: | Replacement is machined to accept a Tone (Exciter) Ring for Anti-Lock brakes. | |
| Spoke Wheel Specifications: | ||
| Finished Weight: | 111 | |
| Spoke Wheel Capacity (lbs): | 11500 | |
| Number of Spokes: | 6 | |
| Spoke Wheel Size: | 20 | |
| Rim Size: | 8.0 Maximum | |
| Axle Group 1: | R28 | |
| Axle Group 2: | ||
| Outer Bearing Cup: | 47620 | |
| Outer Bearing Cone: | 47679 | |
| Inner Bearing Cup: | HM516410 | |
| Inner Bearing Cone: | HM516449 | |
| Bearing Cup Spacing: | 4.94 | |
| A-Drive Stud/Hub Cap Bolt Circle: | 7.5 | |
| B-Drive Stud/Hub Cap Hole Pattern: | (6) .62-11 | |
| C-No of Rim Studs: | 6 | |
| Rim Stud Size: | 0.75 | |
| D-No of Drum/Rotor Bolts: | 6 | |
| Drum/Rotor Bolt Size: | 0.62 | |
| E-Spoke Offset: | -1.32 | |
| F-Drum/Rotor Mount Offset: | -0.88 | |
| G-Drum/Rotor Pilot Diameter: | 11 | |
| H-Drum/Rotor Bolt Circle: | 12.75 | |
| I-Seal Bore Diameter: | 6.25 | |
| J-Overall Length: | 10.06 | |
| K-Spoke Length: | 7.06 | |
| Brake Drum Applications: | ||
| ||
| Disc Brake Rotor Applications: | ||
| ||
| Service Hardware: | ||
| Drum Bolt Part No: | WP373 | |
| Rotor Screw/Bolt Part No: | ||
| Hub Cap Part No: | ||
| Cap Screw/Stud Part No: | ||
| Hub Cap Gasket Part No: | ||
| Drum/Rotor Washer Part No: | W889 | |
| Hub Cap Bolt Part No: | ||
| Drum/Rotor Locknut Part No: | W888 | |
| Hub Cap Lockwasher Part No: | ||
| Grease Slinger Part No: | ||
| Drive Stud Part No: | W1341 | |
| Rim Stud Part No: | W855 | |
| Drive Nut Part No: | WP37 | |
| Rim Nut Part No: | WP148 | |
| Drive Lockwasher Part No: | WP593-10 | |
| Rim Clamp/Spacer Band Part No's: | W1138 | WP380 View Clamp View Band | |
| Exciter (Tone) Ring Part No's: |
| |
| Special Information: | Serviced by RX248K. | |
| Dimensions in parentheses () indicate measurement is inboard of inner cup seat. | ||
