CENTRIC 320.47011 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.47011 Specifications
Product Attributes
| Weight [cntrc] Kgs | 4.770 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 10.500 |
| Misc Holes [cntrc] | 2 |
| Disc Mounting [cntrc] | Floating / DIH |
| Discard Thickness | 0.335 IN |
| Discard Thickness | 8.500 MM |
| Nominal Thickness | 10.000 MM |
| Nominal Thickness | 0.394 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 65.700 MM |
| Overall Height | 2.587 IN |
| Outside Diameter | 265.500 MM |
| Outside Diameter | 10.453 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 170.100 MM |
| Nominal Drum Diameter | 6.697 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.287 IN |
| Center Hole Diameter | 58.100 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.800 MM |
| Stud/Lug Hole Diameter | 0.504 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590251517 |
CENTRIC 320.47011 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 96121FZN, 96121R |
| N/A | 90013008 |
CENTRIC 320.47011 Cross References
We have 2 alternatives for the 320.47011 by CENTRIC:
